(888) 312-8812 Login SignupRAYBESTOS 981026R Raybestos R-Line Brake Rotor
$6499
Limited availability at this price!
In Stock
Get it by Thursday, Dec 18
RAYBESTOS 981026R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2018-2014 Mazda 6 Front
RAYBESTOS 981026R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.67 IN |
| Center Hole Diameter | 67.8 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.024 IN |
| Discard Thickness | 26 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 7.108 IN |
| Inside Diameter | 180.55 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.488 IN |
| Mounting Bolt Hole Circle Diameter | 114 MM |
| Mounting Bolt Hole Diameter | 0.52 IN |
| Mounting Bolt Hole Diameter | 13.2 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28 MM |
| Outside Diameter | 11.68 IN |
| Outside Diameter | 296.65 MM |
| Overall Height | 2.026 IN |
| Overall Height | 51.45 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| UPC | 00887213094251 |
RAYBESTOS 981026R Part Interchanges
| Brand | Part Number |
|---|---|
| Mazda | GHP933251, GHP933251A, GHR133251, GHR133251A, GV9B33251A |
| BrakeBest | 921715RGS, 981026, 981026FZN, 981026R |
| Centric Parts | 120.45096, 121.45084, 121.45096 |
| Advance Auto Parts | YH425145P |
| Autopartsource | 474880 |
| UAP | 2901194, R45084 |
| NAPA BRAKES | SDK6763 |
| Wagner Brake | BD180847E |
| Dynamic Friction Company | 604-80080 |
| DuraGo | BR901194 |
| Qualis | 44772, 44893 |
RAYBESTOS 981026R Fits Vehicles
- Mazda 6 (2014-2018)
RAYBESTOS 981026R Cross References
We have 17 alternatives for the 981026R by RAYBESTOS:
