CENTRIC part description

Product Description

C-Tek Standard Brake Rotor

Features & Benefits

  • Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket

Product Attributes

Vane Style [cntrc] Straight
Notes [cntrc] U Shaped
Weight [cntrc] Kgs 14.320
Disc Mounting [cntrc] Behind the Hub
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Misc Holes [cntrc] 0
Weight [cntrc] Lbs 31.500
Product Grade [cntrc] Standard
Discard Thickness 1.035 IN
Discard Thickness 26.290 MM
Nominal Thickness 29.900 MM
Nominal Thickness 1.177 IN
Overall Height 118.000 MM
Overall Height 4.646 IN
Outside Diameter 324.000 MM
Outside Diameter 12.756 IN
Mounting Bolt Hole Quantity 8
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Vented
Bolt Thread Pitch 13.000 IN
Bearings Included No
Center Hole Diameter 6.524 IN
Center Hole Diameter 165.700 MM
Mounting Bolt Hole Circle Diameter 8.000 IN
Mounting Bolt Hole Circle Diameter 203.200 MM
Mounting Bolt Hole Diameter 0.050 IN

Additional Information

Harmonized Tariff Code (HTS) 8708305030
Harmonized Tariff Code (Schedule B) 8708300050
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
UPC 889590010572

Part Interchanges

CENTRIC 121.75001 Cross Reference

We have 1 alternatives for the 121.75001 by CENTRIC:

Fits Vehicles

  • Workhorse W42 (2006-2011)
  • Hino 185 (2005-2010)
  • Hino 165 (2005-2010)
  • Workhorse Custom Chassis W42 (2006-2008)
