Centric 123.99006 - C-Tek Standard Brake Drum
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Misc Holes [cntrc] | 1 |
| Weight [cntrc] Kgs | 3.568 |
| Weight [cntrc] Lbs | 7.850 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 100.000 |
| Bolt Circle Diameter [cntrc] In | 3.937 |
| Hub Hole / Register [cntrc] Mm | 65.000 |
| Hub Hole / Register [cntrc] In | 2.559 |
| Height [cntrc] Mm | 58.700 |
| Friction Surface Width [cntrc] Mm | 51.000 |
| Friction Surface Width [cntrc] In | 2.008 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 201.500 MM |
| Maximum Brake Diameter (Discard) | 7.933 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 239.700 MM |
| Outside Diameter | 9.437 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 14.000 MM |
| Mounting Hole Diameter | 0.551 IN |
| Nominal Drum Diameter | 200.000 MM |
| Nominal Drum Diameter | 7.874 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 889590001389 |
Part Interchanges
Fits Vehicles
- Volkswagen Up! (2016-2018)
- Volkswagen Saveiro (2015-2017)
- Volkswagen Gol (2016-2019)
- Volkswagen Gol Sedan (2010-2013)
- Volkswagen Derby (2006-2008)
- Seat Ibiza (2002-2007)
- Seat Cordoba (2001-2009)
