CENTRIC part description

Product Description

C-Tek Standard Brake Rotor

Features & Benefits

  • Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket

Product Attributes

Misc Holes [cntrc] 2
Weight [cntrc] Kgs 10.410
Product Grade [cntrc] Standard
Disc Mounting [cntrc] Floating
Weight [cntrc] Lbs 22.900
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Discard Thickness 1.102 IN
Discard Thickness 28.000 MM
Nominal Thickness 30.000 MM
Nominal Thickness 1.181 IN
Overall Height 2.067 IN
Overall Height 52.500 MM
Outside Diameter 300.000 MM
Outside Diameter 11.811 IN
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Vented
Bearings Included No
Center Hole Diameter 96.200 MM
Center Hole Diameter 3.787 IN
Mounting Bolt Hole Circle Diameter 139.700 MM
Mounting Bolt Hole Circle Diameter 5.500 IN
Stud/Lug Hole Quantity 6

Additional Information

Harmonized Tariff Code (HTS) 8708305030
Harmonized Tariff Code (Schedule B) 8708300050
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
UPC 805890825623

Part Interchanges

Fits Vehicles

  • Hyundai Starex (2019)
