Star Safety Technologies DLX3-A - Versa Star®, three LED array, Black bezel, flush or bracket mount, 10-16V

Part in image and product description below is representative and may not represent actual part. Please verify the part type and color using the part number.

Features

• High intensity Star Generation IV LEDs
• 12 different selectable flash patterns in either of two phases, plus steady-on
• S-Link System™ synchronizing capabilities with other Star LED units
• Versatile LED warning lights that are built with fully encapsulated circuitry
• Can be mounted just about anywhere, interior or exterior
• Size is the same between options, allowing for easy relocation or reconfiguration
• Include the same snap on Black (standard), Chrome, or White bezel optional
• Optional mounting brackets are also available on the mounting bracket page
• Reverse polarity protected and current limiting protection over the entire operating voltage

Specifciations

• Voltage:
  • DLX3 10-16V DC
  • DLX4, DLX6 & DLX6F 10-30V DC
• Amp Draw:
  • DLX3 .29 amps
  • DLX4 0.7 amps @ 12V DC, 0.3 @ 24V DC
  • DLX6 & DLX6F 0.9 amps @ 12V DC, 0.5 amps @ 24V DC (amp draw will vary depending on the color the LED heads used and the flash pattern selected)
• Approvals:
  • DLX3: Class I ( Blue, Red,) Class II (Amber, White)
  • DLX3H-A: SAE J595 Class I (Amber,) California Title 13 (Amber)
  • DLX4: SAE J595 Class I (Amber, Blue, Red, White) California Title 13 (Blue, Red)
  • DLX6 & DLX6F: SAE J595 Class I (Amber, Blue, Red, White, Red/Blue) California Title 13 (Amber, Blue, Red, Red/Blue)
