Peterson Lighting M823R-10 - 820R-10/823R-10 LumenX® Oval LED Stop, Turn and Tail Light, AMP - Red Flange Mount
- Part Number
- M823R-10
- Manufacturer
- PETERSON LIGHTING
- Description
-
820R-10/823R-10 LumenX® Oval LED Stop, Turn and Tail Light, AMP - Red Flange Mount
details
$1,04950
Package Price for 50 Units
@ $20.99 per unit
In stock
limited availability at this price!
. Learn more
PETERSON LIGHTING part description
820R-10/823R-10 LumenX® Oval LED Stop, Turn and Tail Light, AMP
Peterson Lighting LumenX® Oval LED Stop, Turn & Tail Light
For enhanced trucking safety, equip your truck with a high-quality Peterson Lighting LumenX® oval LED stop, turn & tail light. This product effectively combines all three crucial functions—stop, turn, and tail— into one industry-standard light.
Features & Benefits
- A flange-mount 10-diode oval LED with white diodes behind the red lens
- With a fully illuminated lens because of advanced optics
- Comes with an AMP-compatible connector and flange that is integrated into the housing to form a single unit
- Provides voltage protection and consistent light output over the entire voltage range with its regulated design
- Product’s operating range is 9 to 32 volts and can be used in 12V and 24V vehicle systems
- Designed to meet FMVSS 108 requirements in vertical, horizontal, or any 360-degree position
- Engineered to meet the needs of any stop tail turn lighting situation
Product Description
LED STOP/TURN/TAIL, OVAL, AMP, FLANGE-MOUNT 7.88"X3.63", MV
Features & Benefits
- 11 diodes.
- Defender harness & lighting system approved.
- Lumenx® lens and circuitry.
- Made in USA.
- Multivolt version available.
- Voltage Regulated.
- White diodes behind red lens.
- Advanced optics fully illuminate lens.
- AMP-compatible connector integrated into housing.
- Regulated design provides voltage protection and consistent light output over a wide voltage range.
- 823-10 has flange welded to light, forming a single unit.
- 9-32 volt operating range is compatible with 12V and 24V vehicles.
- Meets FMVSS 108 requirements in horizontal, vertical or any 360° position.
- 820 kit includes light, grommet and 817-49 plug.
- 823 kit includes light and 817-49 plug.
417-49: hardshell plug (poly pack - std qty 6)
Product Attributes
| Bulb Technology | LED |
| Bulb/diode Count | 10 |
| California Proposition 65 Required | Y |
| Container Type | bulk pack |
| Family | LumenX |
| Height | 3.63 in |
| Integral Reflex | N |
| Length | 7.88 in |
| Lens Color | red |
| Light Color | red |
| Marine Use | Y |
| Maximum Voltage | 32 Volts |
| Minimum Voltage | 9 Volts |
| Mounting Type | flange |
| Multi-volt | Y |
| Regulatory Compliance | DOT |
| Shape | oval |
| Termination | AMP |
| Voltage | 24 Volts |
| Width | 1.45 in |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8512204000 |
| UPC | 00044464999791 |
| VMRS Code | 034002059 |
PETERSON LIGHTING M823R-10 Cross Reference
We have 1 alternatives for the M823R-10 by PETERSON LIGHTING:
Peterson Lighting® is a family-owned company that produces and distributes vehicle safety lighting systems mirrors, and other related safety products and accessories. It has been in the business for 75 years, and currently, it offers over 2,200 products designed for various applications, including tilt-bed and cargo vehicles and light- and medium-duty trailers. Peterson Lighting believes that full commitment to quality is its responsibility as a market leader. All its components are designed and manufactured only in its ISO 9001/QS-9000-certified facility in Grandview, MO. This facility is handled by knowledgeable and highly skilled specialists, who are as dedicated and passionate as the company when it comes to quality.
