Gates G20240-0808 - Female Flat-Face O-Ring Swivel - 90 Bent Tube (GlobalSpiral)
$4999
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
GATES part description
Product Description
Female Flat-Face O-Ring Swivel - 90 Bent Tube (GlobalSpiral)
Features & Benefits
- "Bite-the-wire" crimp for improved coupling retention
- “Bite-the-wire” crimp for improved coupling retention
- Tested to an industry-leading 1,000,000 impulse cycles
- +250degF temperature capability for longer assembly life
- +250°F temperature capability for longer assembly life
- Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance than the SAE Standard
Product Attributes
| Drop Length | 1.61 IN |
| 9929 | 1.91 IN |
| Length | 3.39 IN |
| Coupling Description | GlobalSpiral Female Flat-Face O-Ring Swivel - 90 Bent Tube |
| Industrial Description | 8GS-8FFORX90M |
| Thread Size | 13/16-16 |
| Inside Diameter | .5 IN |
| 9952 | All Gates MegaSys Four and Six-Spiral Wire Hydraulic Hose Up to 8,000 psi |
| 9923 | 24 MM |
| Inside Diameter | 12.7 MM |
| 1874 | 40.9 MM |
| 9929 | 48.5 MM |
| Length | 86.1 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 7326908688 |
| Country of Origin (Primary) | US |
| UPC | 00072053399639 |
| VMRS Code | 059032012 |
| UNSPSC | 31163000 |
Part Interchanges
