(888) 312-8812 Login SignupGATES 19394 Premium Molded Heater Hose
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
GATES 19394 Part Description
Manufacturer
Product Description
Premium Molded Heater Hose
Application Summary
2009-04 Toyota, Prius, 4-Cyl. 1.5 L Electric Assist, Heater to Aux. W.P.
Features & Benefits
- Has all the quality features of Gates molded coolant hose and similar to OEM specifications
- Engineered to resist electrochemical degradation - the leading cause of hose failure
- Engineered to resist electrochemical degradation – the leading cause of hose failure
- EPDM tube, synthetic fiber knit reinforcement, EPDM cover
- Meets SAE 20R3 Type EC Class D-1 and D-2 specifications
- Temperature Range: -40 Deg. F to 275 Deg. F (-40 Deg. C -135 Deg. C)
- Note: Gates recommends replacing hose clamps each time a new coolant hose is installed
- Caution: Do not use for fuel or oil transfer applications
GATES 19394 Specifications
Product Attributes
| Centerline Length | 16.3 IN |
| Branch Quantity | 0 |
| End 1 Inside Diameter | .63 in |
| End 2 Inside Diameter | .63 in |
| Quick Connect Fitting Quantity | 0 |
| Material | EPDM |
| Molded | Yes |
| Centerline Length | 414 MM |
| End 1 Inside Diameter | 16 MM |
| End 2 Inside Diameter | 16 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4009310000 |
| Country of Origin (Primary) | US |
| UPC | 00770075149385 |
| VMRS Code | 042010004 |
| UNSPSC | 40142000 |
GATES 19394 Part Interchanges
| Brand | Part Number |
|---|---|
| ACDelco | 14445S |
| Dayco | 87925, C87925 |
| Carquest | 19394 |
| Toyota | 8724547230 |
| NAPA Belts/Hose | 11394 |
GATES 19394 Fits Vehicles
- Toyota Prius (2004-2009)
GATES 19394 Cross References
We have 1 alternatives for the 19394 by GATES:
