Gates 85798 - Global G2XH 2-Wire Braid Xtreme Heat Hose - SAE 100R2 Type S
$51399
5 day lead time
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
GATES part description
Product Description
Global G2XH 2-Wire Braid Xtreme Heat Hose - SAE 100R2 Type S
Features & Benefits
- For use with GlobalSpiral Couplings [G20 Series], GlobalSpiral Plus Couplings [G22 Series], MegaCrimp Couplings [G25 Series] and Stainless Steel Braid Couplings [G17 Series]
- Blue, oil- and abrasion-resistant, thin synthetic rubber cover indicates higher temperature hose
- Tested to industry-standard 600,000 impulse cycles
- Meets Flame Resistance Acceptance Designation MSHA 2G
- Temperature Range: Petroleum-Based Fluids: -40 Deg. F to +300 Deg. F (-40 Deg. C to +149 Deg. C); Phosphate Esters Fluids: as recommended by the fluid manufacturers, but within a range of -40 Deg. F to +212 Deg. F (-40 Deg. C to 100 Deg. C)
Product Attributes
| Inside Diameter | .25 IN |
| Outside Diameter | .59 IN |
| 9879 | 4 IN |
| Tube Description | Black, Oil & Chemical-Resistant, Synthetic Rubber |
| Hose Material | CPE - Type J |
| Reinforcement Material | Two Braids, High-Tensile Steel Wire |
| Cover Material | Thin Synthetic Rubber - CSM - Type M |
| Cover Type | Oil, Abrasion & Flame Resistant |
| Cover Color | Blue |
| 9856 | MegaCrimp |
| 9453 | 100R2 |
| 9954 | 853 2SN |
| 9953 | 1436 2SN R2 |
| Product Type | Global G2XH 2-Wire Braid Xtreme Heat Hose - SAE 100R2 Type S |
| Industrial Description | 4G2XHX50FT |
| Type | Hydraulic Hose |
| Hose Pressure Description | High Pressure |
| Maximum Working Pressure | 6000 PS |
| Burst Pressure | 24000 PS |
| Temperature Rating | -40 Deg. F to +300 Deg. F (Petroleum-Base Fluid); -40 Deg. F to +212 Deg. F (Phosphate Ester Fluids) |
| Length | 50 FT |
| 9941 | 4 |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 4009210000 |
| UPC | 00770075257585 |
| VMRS Code | 059032029 |
| UNSPSC | 40142020 |
