STRONG ARM LIFT SUPPORTS part description

Product Description

Hood Lift Support

Features & Benefits

  • Exact fit original equipment design guarantees correct fit and function
  • Engineered and built to meet or exceed original equipment quality standards
  • Individually tested for performance and reliability
  • Hardened, nitride plated steel shaft provides optimal durability
  • Rubber O-ring piston seal prevents leakage for a controlled lift and consistent performance
  • Heavy gauge steel body is electrostatically painted and heat cured to OE specs
  • Self-Cleaning Piston Assembly provides smooth operation and more reliable performance
  • Upper bushing is manufactured with quality precision providing exact fit and promotes longer operating life
  • No special installation tools required

Product Attributes

Compressed Length 10.41 IN
End 1 Type Blade w/Retainer
End 2 Type Blade w/Retainer
Maximum Force 103 LB
Cylinder Outside Diameter 15 MM
Universal Or Specific Fit Specific
Extended Length 15.28 in
Stroke Length 4.87 IN
Inner Shaft Diameter 8 MM
Outer Cylinder Color Black
Outer Cylinder Material Steel
6225 7.93 MM
6226 6 MM
Internal Rebound Spring No

Additional Information

Country of Origin (Primary) TR
Harmonized Tariff Code (HTS) 8302303010
Warranty Time 12
Warranty Time UOM MO
UPC 00043645562915

Part Interchanges

Fits Vehicles

  • Pontiac Bonneville (1987-1991)
  • Oldsmobile Delta 88 (1986-1991)
  • Oldsmobile 98 (1985-1990)
  • Cadillac Brougham (1987-1990)
  • Cadillac Fleetwood (1985-1990)
  • Cadillac DeVille (1985-1990)
  • Cadillac Commercial Chassis (1985-1990)
  • Buick Electra (1985-1990)
