(888) 312-8812 Login SignupDELPHI ES10685 Oxygen Sensor
$11499
Limited availability at this price!
5 Day Lead Time
Get it by Tuesday, Jan 6
DELPHI ES10685 Part Description
DELPHI ES10685 Specifications
Product Attributes
| Package Contents | Oxygen Sensor, Instruction Sheet |
| Position(s) | Front, Front Left. For the position specific to your vehicle, refer to the Applications. |
| Wiring Harness Length | 11.4 IN |
| Wiring Harness Length | 290.0 MM |
| Sensor Type | Heated |
| Terminal Type | Blade |
| Universal Or Specific Fit | Specific |
| Band Type | Narrow |
| Wire Quantity | 3 |
| Grade Type | Regular |
| Connector Shape | Oblong |
| Terminal Quantity | 3 |
| Connector Gender | Male |
| Terminal Gender | Male |
| Thread Diameter | 0.7 IN |
| Wrench Size | 22mm |
| Thread Size | M18x1.5 |
| Overall Length | 12.6 IN |
| Overall Length | 320.0 MM |
| Mounting Type | Threaded |
| Thread Diameter | 18.0 MM |
| Wire Gauge Measurement | 20.0 GU |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9027100000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 9027102000 |
| UPC | 00689604118344 |
| VMRS Code | 045021011 |
| UNSPSC | 41111924 |
DELPHI ES10685 Part Interchanges
| Brand | Part Number |
|---|---|
| N/A | 25023096, FSC518861, FSC518861A, KLC718861, KLC718861A, KLC718861B, 138303, 138306, F62Z9F472CC, F62Z9F472EE, FSC518861A9U, KLC718861B9U, 1563076, DY785, 2343010, 2343084 |
| Bosch | 13284, 13547 |
| Wells | SU2096, SU4610 |
| NTK | 22033, 22034 |
| ACDelco | 2131273, 2131285, 2131365, 2131368, 2131420, 2131488, 2131489 |
| Standard Motor Products | SG549, SG647 |
| BorgWarner | OS223, OS693 |
| Oextra | REA1434, REA1459 |
| Beck/Arnley | 156-3076 |
| DENSO Auto Parts | 234-3010, 234-3084 |
| Motorcraft | DY-785 |
| Kem | 138-303, 138-306 |
| Ford | F62Z 9F472-CC, F62Z 9F472-EE, FSC5-18-861A9U, KLC7-18-861B9U |
| Mazda | FSC5-18-861, FSC5-18-861A, FSC5-18-861A9U, KLC7-18-861, KLC7-18-861A, KLC7-18-861B, KLC7-18-861B9U |
| Walker Products | 250-23096 |
DELPHI ES10685 Fits Vehicles
- Mazda 626 (1996-1997)
- Mazda MX-6 (1996-1997)
- Ford Probe (1996-1997)
DELPHI ES10685 Cross References
We have 1 alternatives for the ES10685 by DELPHI:
