Name: Dana 2-3-15871X 1330 Series Drive Shaft Transmission Slip Yoke - Steel, 30/32 Spline, SR Style
SKU: 2315871x
Price: 149.99 USD
Availability: InStock

DANA part description

Series:	1330
Outside Yoke Dimension (E):	3.875 in.
Bearing Cap Diameter (D):	1.062 in.
To End of Spline (J):	6.102 in.
Hub Diameter (R):	1.731 in.
Spline Outside Diameter (STD):	1.378 in.
No. of Splines:	30/32 I
Involute:	I
Style:	SR
Counter Bore Diameter:	1.375
Counter Bore Depth:	.393
Material:	Steel
Number of Splines Based On:	32
C-Line to Washer Face:	1.128
Type of Hub:	Ground Hub

Features & Benefits

Quench And Tempered (Heat Treated)
High Strength Forged
Precision Machined
Electroless Nickle-Plated

Product Attributes

Series	1330
Material	Steel
Style	SR
No. Of Splines	30/32 I
Bearing Cap Diameter (D) In.	1.062 IN
Outside Yoke Dimension (E) In.	3.875 IN
Spline O.D. (STD)	1.378 IN
To End Of Spline (J) In.	6.102 IN
Type of Hub	Ground Hub
C-Line to Washer Face	1.128 IN
Involute	I
Number of Splines Based On	32
Counter Bore Depth	.393 IN
Counter Bore Diameter	1.375 IN
Spline O.D. (MM)	35 MM
Hub Diameter (R) In.	1.731 IN

Additional Information

Country of Origin (Primary)	US
Harmonized Tariff Code (Schedule B)	8708990000
Harmonized Tariff Code (HTS)	8708990000
UPC	00023913276607
VMRS Code	024002038

Part Interchanges

Navistar DS2315871X
