Name: Four Seasons 33288 Steel Filter Drier
SKU: 33288
Price: 33.99 USD
Availability: InStock

FOUR SEASONS part description

Steel Filter Drier

Product Description

Steel Filter Drier

Features & Benefits

As a manufacturer in accumulator/filter driers, we offer quality units produced in a ISO/TS16949 & ISO14001 certified facility. State-of-the-art equipment and high quality materials ensure product integrity for long lasting performance customers rely on.
As a manufacturer in accumulator/filter driers, we offer quality units produced in a ISO/TS16949 & ISO14001 certified facility. State-of-the-art equipment and high quality materials ensure product integrity for long lasting performance.
Our accumulator / filter driers feature quality welds for a durable, leak-free design in addition to high-quality desiccant for appropriate absorption. For easy installation, necessary gaskets, o-rings and seal are included as well.
The accumulator / filter drier acts as a filter by removing moisture and contaminants from the air conditioning system. Such contaminants cannot be removed by flushing, therefore replacing the accumulator / filter drier is essential.
The absorption of moisture in the system is done through the use of a desiccant bag. A leaking or “open” system can cause the bag to become saturated within a few hours making the accumulator/filter drier ineffective.
The absorption of moisture in the system is done through the use of a desiccant bag. A leaking or "open" system can cause the bag to become saturated within a few hours making the accumulator/filter drier ineffective.
Replacement of the accumulator / filter drier is required to validate compressor warranty and must be replaced anytime the system is serviced.

Product Attributes

Body Length	7.000 IN
797	0.63 in
Mounting Bracket Included	Not Included
Body Diameter	3.000 IN
In Line Filter Outlet Fitting Type	Male
In Line Filter Material	Desiccant
Desiccant Replaceable	Not Replaceable
1178	0.63 in
Material	Steel
Fuse Plug	Yes
Outlet Fitting Type	Male Insert O-Ring
Moisture Indicator Window	Yes
Desiccant	Yes
Type	Washer Not Included
Inlet Filter Fitting Type	Male
Inlet Fitting Type	Male Insert O-Ring
Bracket?	w/ Bracket
Connector B Type	Male Insert O-Ring
Connector Type	Male Insert O-Ring
Description	Filter Driers
Dia. Mm	76.2 mm
Gasket / Seals?	Included
Inlet Dia. Fraction	5/8 in
Length Mm	177.8 mm
Meets / Exceeds Oem?	Yes
New or Reman	New
O-ring A Number/desc	24616 / Green O-Ring
O-Ring A Quantity	2
O-ring B Number/desc	24606 / Green O-Ring
O-Ring B Quantity	1
Outlet Fraction	5/8 in
Outlet In	0.63 in
Overall Depth In	7.000 in
P. R. V.?	No
Service Port Qty.	1
Service Port?	w/o Service Port
Sight Glass?	Yes
Stud?	No
Style	Steel Filter Drier
Switch Port Dia. In	0.250 in
Switch Port Dia.mm	6.350 mm
Switch Port?	w/ Switch Port
Des Replaceable?	Not Replaceable
Desiccant Included?	Yes
Dia. In	3.000 in
Filter Material	Desiccant
Fitt Thrd Dia In	0.63 in
Fuse Plug?	Yes
In Fltr Fitt Typ Gen	Male
Inlet Dia. In	0.63 in
Inlet Type	Male Insert O-Ring
Length In	7.000 in
Material	Steel
Moisture Indicator?	Yes
Mounting Hardware?	Not Included
Out Fitt Type Gen	Male
Outlet Type	Male Insert O-Ring
Washer Type	Washer Not Included

Additional Information

Country of Origin (Primary)	CN
Harmonized Tariff Code (Schedule B)	8415908045
Harmonized Tariff Code (HTS)	8421290065
MSDS Sheet Number	0
Stock Status	S
UPC	00096361332881

Part Interchanges

Fits Vehicles

Nissan 720 (1980-1986)
