Centric 120.67078 - Centric Premium Brake Rotor
$16349
MSRP: $227.55
Save: $64.06
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| Misc Holes [cntrc] | 5 |
| Max Pb Drum Dia [cntrc] In | 9.575 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Max Pb Drum Dia [cntrc] Mm | 243.200 |
| OEM Vane Count [cntrc] | 51 |
| Vane Style [cntrc] | Straight |
| Hat Id [cntrc] In | 9.528 |
| Weight [cntrc] Lbs | 43.150 |
| Disc Mounting [cntrc] | Behind the Hub |
| Hat Id [cntrc] Mm | 242.000 |
| Weight [cntrc] Kgs | 19.610 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 37.400 MM |
| Discard Thickness | 1.472 IN |
| Nominal Thickness | 39.000 MM |
| Nominal Thickness | 1.535 IN |
| Hat Finish | Coated |
| Overall Height | 124.000 MM |
| Overall Height | 4.882 IN |
| Outside Diameter | 390.000 MM |
| Outside Diameter | 15.354 IN |
| Mounting Bolt Hole Quantity | 10 |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 241.000 MM |
| Nominal Drum Diameter | 9.488 IN |
| Bearings Included | No |
| Center Hole Diameter | 5.488 IN |
| Center Hole Diameter | 139.400 MM |
| Mounting Bolt Hole Circle Diameter | 163.100 MM |
| Mounting Bolt Hole Circle Diameter | 6.421 IN |
| Mounting Bolt Hole Diameter | 12.860 MM |
| Mounting Bolt Hole Diameter | 0.506 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890621775 |
Part Interchanges
- Raybestos Brakes 680374
- Raybestos Brakes 781830
- Raybestos Brakes 781830R
- Wagner BD126443
- BD126443
- E125-72-083
- 843AB
- 141394
- 3C342C026C
- 158932
- BR900359
- YH145731
- 42250
- 27421
- 53060
- 42250G
- 52013843AA
- 52013843AB
- 0053466225
- 0053466225001
- 53466225
- 6011139C1
- 68174125AA
- 68174125AB
- 68415393AA
- 5C3Z2C026CA
- 2608016C1
- 780777
- 850300
- 54138
- 880374
- 880374CR
- 90040116
- E12570120
- E12572083
CENTRIC 120.67078 Cross Reference
We have 12 alternatives for the 120.67078 by CENTRIC:
Fits Vehicles
- International TerraStar (2010-2015)
- International CF600 (2005-2010)
- International CF500 (2005-2010)
- IC Corporation AC Commercial Bus (2012-2015)
- Dodge Ram 5500 (2008-2010)
- Ford LCF (2006-2010)
- IC Corporation AE School Bus (2015)
- Ford F-550 Super Duty (2005-2016)
- Dodge Ram 4500 (2008-2010)
- Ford F-450 Super Duty (2005-2016)
- Ram 5500 (2011-2022)
- Ram 4500 (2011-2022)
- Sterling Truck Bullet 55 (2008-2009)
- Sterling Truck Bullet 45 (2008-2009)
