DELPHI FE0119 Part Description
DELPHI FE0119 Specifications
Product Attributes
| Position(s) | In-Tank |
| Item Grade | Standard Replacement |
| System Pressure | 44 psi |
| Package Contents | Electric Fuel Pump, Hose Clamps, Hose Piece, Isolator, Pall Nut, Seal, Instruction Sheet |
| Fuel Sending Unit Included | No |
| Negative Ground | No |
| Inlet Outside Diameter | 11.0 MM |
| Outlet Outside Diameter | 0.313 IN |
| Outlet Outside Diameter | 7.9 MM |
| Length | 113.0 MM |
| Fuel Type | Gas |
| Internal Or External | Internal |
| Regulator Included | No |
| Maximum Pressure | 80.0 PS |
| Terminal Type | Pin |
| Mounting Hardware Included | Yes |
| Wire Quantity | 0 |
| Connector Shape | Rectangle |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 2 |
| Seal And Lock Ring Included | No |
| Connector Gender | Female |
| Terminal Gender | Male |
| Wiring Harness Included | No |
| Strainer Included | No |
| Inlet Type | Strainer |
| Outlet Type | Hose Bead |
| Outlet Quantity | 1 |
| Pump Design | Turbine |
| Mounting Bracket Included | No |
| Voltage | 12.0 2H |
| Average Current Draw | 6.0 68 |
| Average Flow Rating | 26.0 GPH |
| Universal Or Specific Fit | Specific |
| Grade Type | Premium |
| Minimum Pressure | 44 PS |
| Maximum Amperage Draw | 6.0 68 |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Country of Origin (Primary) | TH |
| UPC | 00689604033876 |
| VMRS Code | 044003259 |
| UNSPSC | 40151532 |
DELPHI FE0119 Part Interchanges
| Brand | Part Number |
|---|---|
| General Motors | 25176174, 25177378, 25177379, 88972523, 88974776, 9485691, 94858837, 94856915 |
| N/A | 1951306970, 9500100, 9500101, 9500104, 9500105, 9510001, 9510010, 2322146010, 2322003020, 2322003030, 2322003040, 232200C010, 2322020020, 2322031180, 2322074020, 2322074021, 2322103030, 232210D010, 232210D011, 2322111050, 2322115040, 2322121030, 2322121060, 2322128030, 2322128280, USEP8213, F4224, B0215E, E8392, P72188, B0216E |
| Carter | P72189, P72244, P72245, P72248, P76004, P76182, P72246, P76248, P76578M, P88008, P90007 |
| ACDelco | EP392, EP469, EP470, EP474, EP1004, EP1011, MU1392 |
| EVO Driveline | AFS0416P, A38007, RE0416P |
| Magneti Marelli | 1AMFP00149 |
| Airtex | E8213, E8434, E8404, E8419, E8874M |
| Spectra Premium | SP1123, SP1267, SP9030M, SP9047M |
| Autopart International | 60123 |
| Kem | EFP8213 |
| Toyota | 94856915, 23220-03020, 23220-03030, 23220-03040, 23220-0C010, 23220-20020, 23220-74020, 23220-74021, 23221-03030, 23221-0D010, 23221-0D011, 23221-11050, 23221-11070, 23221-15030, 23221-15040, 23221-16490, 23221-21020, 23221-21030, 23221-21060, 23221-28030, 23221-28280, 23221-46010 |
| Master Parts Division | E8213 |
| BorgWarner | P168E |
| Niehoff | P168E |
| Walbro | TCA320, TCA3307 |
| Beck/Arnley | 152-0894, 152-0895, 152-0910, 152-0914 |
| Bosch | 67484, 67581, 69248, 69487 |
| DENSO Auto Parts | 195130-6970, 950-0100, 950-0101, 950-0102, 950-0103, 950-0104, 950-0105, 950-0202, 951-0001, 951-0002, 951-0007, 951-0010 |
| Carquest | E260149 |
| AutoZone | CFE0119 |
| Datsun/Nissan | 23221-46010 |
| Precision Fuel | E16013, E16055, E16289 |
| Import Direct | E16013, E16230, E16289 |
| MasterPro Fuel Pumps | MPE16013 |
| TruGrade | 5211008 |
DELPHI FE0119 Fits Vehicles
- Scion xB (2004-2006)
- Scion xA (2004-2006)
- Toyota Tacoma (1995-2004)
- Toyota T100 (1993-1998)
- Toyota RAV4 (1996-2005)
- Toyota Tercel (1990-1998)
- Toyota Pickup (1992-1995)
- Toyota Sienna (1998-2000)
- Toyota Previa (1994-1995)
- Toyota Paseo (1992-1998)
- Toyota MR2 Spyder (2000-2005)
- Toyota Echo (2000-2005)
- Toyota Corolla (1993-2002)
- Toyota Celica (1994-2005)
- Toyota Camry (1992-2001)
- Toyota Avalon (1995-1999)
- Toyota 4Runner (1992-2002)
- Lexus ES300 (1992-2001)
- Pontiac Vibe (2003-2006)
- Geo Prizm (1993-1997)
- Chevrolet Prizm (1998-2002)
