Name: Four Seasons 33319 Steel Filter Drier
SKU: 33319
Price: 24.99 USD
Availability: InStock

FOUR SEASONS part description

Filter Drier /Steel

Product Description

Steel Filter Drier

Features & Benefits

As a manufacturer in accumulator/filter driers, we offer quality units produced in a ISO/TS16949 & ISO14001 certified facility. State-of-the-art equipment and high quality materials ensure product integrity for long lasting performance customers rely on.
As a manufacturer in accumulator/filter driers, we offer quality units produced in a ISO/TS16949 & ISO14001 certified facility. State-of-the-art equipment and high quality materials ensure product integrity for long lasting performance.
Our accumulator / filter driers feature quality welds for a durable, leak-free design in addition to high-quality desiccant for appropriate absorption. For easy installation, necessary gaskets, o-rings and seal are included as well.
The accumulator / filter drier acts as a filter by removing moisture and contaminants from the air conditioning system. Such contaminants cannot be removed by flushing, therefore replacing the accumulator / filter drier is essential.
The absorption of moisture in the system is done through the use of a desiccant bag. A leaking or “open” system can cause the bag to become saturated within a few hours making the accumulator/filter drier ineffective.
The absorption of moisture in the system is done through the use of a desiccant bag. A leaking or "open" system can cause the bag to become saturated within a few hours making the accumulator/filter drier ineffective.
Replacement of the accumulator / filter drier is required to validate compressor warranty and must be replaced anytime the system is serviced.

Product Attributes

797	0.375 in
In Line Filter Material	Desiccant
Type	Washer Not Included
1178	0.625 in
Inlet Filter Fitting Type	Male
In Line Filter Outlet Fitting Type	Male
Desiccant Replaceable	Not Replaceable
Outlet Fitting Type	Male Insert O-Ring
Desiccant	Yes
Moisture Indicator Window	No
Material	Steel
Mounting Bracket Included	Not Included
Body Length	6.000 IN
Inlet Fitting Type	Male Insert O-Ring
Fuse Plug	No
Body Diameter	3.000 IN
Bracket?	w/o Bracket
Connector B Type	Male Insert O-Ring
Connector Type	Male Insert O-Ring
Description	Filter Driers
Dia. Mm	76.2 mm
Gasket / Seals?	Included
Inlet Fraction	3/8 in
Inlet In	0.375 in
Inlet Mm	9.525 mm
Length Mm	152.4 mm
Meets / Exceeds Oem?	Yes
New or Reman	New
O-ring A Number/desc	[24606] / Green O-Ring
O-Ring A Quantity	3
Outlet Fraction	3/8 in
Outlet In	0.375 in
Outlet Mm	9.525 mm
Overall Depth In	6.000 in
P. R. V.?	No
Service Port?	w/o Service Port
Sight Glass?	No
Stud?	No
Style	Steel Filter Drier
Switch Port?	w/ Switch Port
Des Replaceable?	Not Replaceable
Desiccant Included?	Yes
Dia. In	3.000 in
Filter Material	Desiccant
Fitt Thrd Dia In	0.625 in
Fuse Plug?	No
In Fltr Fitt Typ Gen	Male
Inlet Dia. In	0.375 in
Inlet Type	Male Insert O-Ring
Length In	6.000 in
Material	Steel
Moisture Indicator?	No
Mounting Hardware?	Not Included
Out Fitt Type Gen	Male
Outlet Type	Male Insert O-Ring
Washer Type	Washer Not Included

Additional Information

Country of Origin (Primary)	CN
Harmonized Tariff Code (Schedule B)	8415908045
Harmonized Tariff Code (HTS)	8421290065
MSDS Sheet Number	0
Stock Status	S
UPC	00096361333192

Part Interchanges

FOUR SEASONS 33319 Cross Reference

We have 1 alternatives for the 33319 by FOUR SEASONS:

SUNAIR ARD-1014

Fits Vehicles

Autocar C / DC (1983-1986)
Autocar Construcktor (1983)
Autocar ACM (1983)
Peterbilt 387 (1981-1982)
Peterbilt 352 (1981)
Autocar S (1983-1984)
Peterbilt 357 (1986)
Peterbilt 353 (1981-1986)
Peterbilt 372 (1990-1993)
Peterbilt 379 (1986)
Peterbilt 362 (1981-1986, 1990-1993)
Peterbilt 348 (1981-1984)
Peterbilt 310 (1981-1986)
Autocar DS (1983-1988)
Autocar DK (1983-1988)
Autocar ACL (1983-1988)
Peterbilt 349 (1984-1986)
Autocar AT (1983-1988)
Peterbilt 359 (1981-1986)
Peterbilt 200 (1973-1978)
Peterbilt 282 (1973-1980)
Mack MS300T Mid-Liner (1985-1989)
Mack MS300P Mid-Liner (1985-1989)
Mack MS250P Mid-Liner (1985-1989)
Mack MS200P Mid-Liner (1985-1989)
Mack CS300T Mid-Liner (1986-1989)
Mack CS300P Mid-Liner (1986-1989)
Mack CS250P Mid-Liner (1986-1989)
Mack CS200P Mid-Liner (1986-1989)
White/GMC J8C0 (1988)
White/GMC WHM (1988)
White WHM (1984-1987)
White WIL (1984-1988)
White/GMC WIL (1988)
White/GMC WCL (1988)
White WXLL (1986-1988)
White WHS (1983-1988)
White WHL (1983-1988)
White WCL (1983-1988)
White WCA (1988)
White/GMC WXLL (1988)
White/GMC WIS (1988)
White/GMC WIM (1988)
White/GMC WHS (1988)
White/GMC WHL (1988)
White WIS (1984-1988)
White/GMC J9C0 (1988)
White WX (1983-1988)
White WIM (1984-1988)
White WCS (1983-1988)
White/GMC WX (1988)
White WCM (1983-1988)
White/GMC WCS (1988)
White/GMC ACM (1988)
White/GMC ACL (1988)
White WIA (1988)
White/GMC WCM (1988)
White/GMC WCA (1988)
White/GMC WIA (1988)
