(888) 312-8812 Login SignupWEATHERHEAD H56906 Eaton Weatherhead H569 Series Engine and Fuel Hose and Tubing
Tap to view 3 more
MSRP: $37.35
$2099
Save $16.36
Limited availability at this price!
In Stock
Get it by Wednesday, Jan 14
WEATHERHEAD H56906 Part Description
Manufacturer
| Abrasion Resistance | Premium |
| Application | Air brake truck, hydraulics, diesel fuel. |
| Bend Radius Min | 4 inch |
| Burst Pressure | 9000 psi |
| Color | Blue |
| Conditional Temperature Range | Hydraulic fluid -55 - 302 F; Air brake -40 - 200 F; Air -40 - 212 F |
| Construction | 3 Braid |
| Cover Material | Fiber |
| Dash Size | -6 |
| Factory Crimp | Yes |
| Impulse Cycle Life | 150000 cycle |
| InsIDe Diameter | 0.31 inch |
| Lay Line Style | Ink Jet |
| OutsIDe Diameter | 0.67 inch |
| Qualified Hose Fittings | 069 E, 247 N |
| Reinforcement Material | Fiber and steel |
| Tube Material | CPE |
| Tube Wall Thickness | 0.18 inch |
| Working Pressure | 2250 psi |
| Working Temperature Max | 200 degree Fahrenheit |
| Working Temperature Min | -40 degree Fahrenheit |
Features & Benefits
- Highly abrasion resistant cover
- Small number of hoses for many fuel options
- Proven reliability with high temperature resistance
- 100R5 Crimp and Reusable Fittings
- SAE J1402 Type AII and DOT/FMVSS-106 approved.
- 100R5 Construction Rubber Hose
WEATHERHEAD H56906 Cross References
| Brand | Part Number |
|---|---|
| GATES | 85682 |
WEATHERHEAD H56906 Customer Reviews
No reviews yet
Be the first to review this product!
WEATHERHEAD H56906 Manufacturer Information
Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
