Name: Weatherhead H54512 Eaton Weatherhead H545 Series Rubber Hydraulic Braided Hose
SKU: h54512
Price: 974.5 USD
Availability: InStock

WEATHERHEAD part description

Abrasion Resistance	Standard
Application	Logging, construction, mining.
Bend Radius Min	4.75 inch
Burst Pressure	12000 psi
Color	Black
Construction	3 Braid
Cover Material	Nylon
Dash Size	-12
Factory Crimp	Yes
InsIDe Diameter	0.75 inch
Lay Line Style	Ink Transfer
OutsIDe Diameter	1.13 inch
Package Form	Box
Qualified Hose Fittings	U, S, 430 U
Reinforcement Material	Wire
Tube Material	Nitrile
Tube Wall Thickness	0.18995 inch
Working Pressure	3000 psi
Working Temperature Max	250 degree Fahrenheit
Working Temperature Min	-40 degree Fahrenheit

Features & Benefits

Maximum durability under harsh operating conditions
Robust construction able to withstand highest pressures
System engineered to extend hose assembly life

Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
