Name: Weatherhead H36608 Eaton Weatherhead H366 Series Engine and Fuel Hose and Tubing
SKU: h36608
Price: 724.5 USD
Availability: InStock

WEATHERHEAD part description

Abrasion Resistance	Premium
Application	Systems for handling high pressure LPG.
Bend Radius Min	4.625 inch
Burst Pressure	1750 psi
Color	Black
Conductivity	Conductive
Construction	3 Braid
Cover Material	Polyester
Dash Size	-8
Factory Crimp	Yes
InsIDe Diameter	0.41 inch
Lay Line Style	Ink Jet
OutsIDe Diameter	0.8 inch
Package Form	Box
Qualified Hose Fittings	069D, 069E, 247N
Reinforcement Material	Polyester and Wire
Tube Material	Nitrile
Tube Wall Thickness	0.18 inch
Working Pressure	350 psi
Working Temperature Max	300 degree Fahrenheit
Working Temperature Min	-40 degree Fahrenheit

Features & Benefits

Highly abrasion resistant cover
Small number of hoses for many fuel options
Proven reliability with high temperature resistance

Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
