(888) 312-8812 Login SignupWEATHERHEAD H24520 OBSOLETE
$1,22450
Package Price for 50 Units
@ $24.49 per unit
Limited availability at this price!
In Stock
Get it by Thursday, Feb 19
WEATHERHEAD H24520 Part Description
Manufacturer
Product Specifications
| Cover Material | Neoprene |
| Dash Size | 20 |
| Hose Family | SAE R16 |
| Max Temperature (C) | 100 |
| Max Temperature (F) | 212 |
| Min Temperature (C) | -40 |
| Min Temperature (F) | -40 |
| Operating Pressure (PSI) | 1625 |
| Operating Pressure (Bar) | 112 |
| Product Line | Weatherhead |
| Tube Material | Nitrile |
| Available Length (ft) | 50 |
| Burst Pressure (Bar) | 448.2 |
| Burst Pressure (psi) | 6500 |
| Description | High Pressure Hydraulic Hose |
| Family | Hose |
| General Application | Most commonly used for high pressure lines on off road construction equipment, farm equipment and other high pressure applications. Compatible with water/glycol, water, generic hydraulic fluids, and diesel fuel. |
| Government Specification | MSHA |
| Hose Base Number | H245 |
| Industry Specification | SAE 100R16, ABS, SAE J1942 |
| Inside Diameter (Fraction) | 1.25 |
| Inside Diameter (in) | 1.25 |
| Inside Diameter (mm) | 31.8 |
| Min Bend Radius (in) | 8.25 |
| Min Bend Radius (mm) | 209.6 |
| Outside Diameter (Fraction) | 1.78125 |
| Outside Diameter (in) | 1.78 |
| Outside Diameter (mm) | 45.2 |
| Reinforcement Material | Two Steel Braids |
| Weight (kg/m) | 1.7 |
| Weight (lb/ft) | 1.14 |
Eaton Weatherhead High-Pressure Hydraulic Hose
The Eaton Weatherhead hydraulic hose is made from premium-quality materials and using advanced manufacturing technology to offer excellent abrasion and chemical resistance. It delivers the flexibility and durability needed in various operating conditions and under the most demanding applications.
Features & Benefits
- MSHA-approved, high-pressure hydraulic hose
- For use on hydraulic systems with diesel fuel, water-glycol based fluids, and generic hydraulic fluids
- Compatible with high-pressure lines on construction and farm equipment and other high-pressure applications
- Stands up to chemical attacks and ensures a leak-free hose assembly
- Meets ABS, SAE 100R16, and SAE J1942 industry specifications
WEATHERHEAD H24520 Cross References
| Brand | Part Number |
|---|---|
| GATES | 86627 |
WEATHERHEAD H24520 Customer Reviews
No reviews yet
Be the first to review this product!
WEATHERHEAD H24520 Manufacturer Information
Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
