WEATHERHEAD part description

Abrasion Resistance Standard
Application Construction.
Bend Radius Min 4.75 inch
Burst Pressure 12180 psi
Color Black
Construction 2-ply braid
Cover Material Neoprene
Dash Size -12
Factory Crimp Yes
InsIDe Diameter 0.75 inch
Lay Line Style Ink Jet
OutsIDe Diameter 1.16 inch
Package Form Box
Qualified Hose Fittings U, S, Z
Reinforcement Material Wire
Tube Material Nitrile
Tube Wall Thickness 0.2031 inch
Working Pressure 3045 psi
Working Temperature Max 250 degree Fahrenheit
Working Temperature Min -40 degree Fahrenheit

Features & Benefits

  • Maximum durability under harsh operating conditions
  • Robust construction able to withstand highest pressures
  • System engineered to extend hose assembly life

Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
