Weatherhead H03924-150 - Eaton Weatherhead H039 Series Rubber Hydraulic Braided hose
- Part Number
- H03924-150
- Manufacturer
- WEATHERHEAD
- Description
-
Eaton Weatherhead H039 Series Rubber Hydraulic Braided hose
details
$3,82350
Package Price for 150 Units
@ $25.49 per unit
Limited Availability
WEATHERHEAD part description
Abrasion Resistance | Standard |
Application | Suction applications for hydraulics, crude fuel and lubricating oils, gasoline, air, water and chemical transfer. |
Bend Radius Min | 5 inch |
Burst Pressure | 600 psi |
Color | Black |
Conductivity | Conductive |
Construction | Multi Braid |
Cover Material | Synthetic Rubber |
Dash Size | -24 |
Factory Crimp | Yes |
InsIDe Diameter | 1.5 inch |
Lay Line Style | Ink Wheel |
Length Configuration | 50, 100, 150 |
OutsIDe Diameter | 2.07 inch |
Qualified Hose Fittings | 430U |
Reinforcement Material | Fabric and Wire |
Tube Material | Synthetic Rubber |
Tube Wall Thickness | 0.29 inch |
Working Pressure | 150 psi |
Working Temperature Max | 275 degree Fahrenheit |
Working Temperature Min | -40 degree Fahrenheit |
Features & Benefits
- Maximum durability under harsh operating conditions
- Robust construction able to withstand highest pressures
- System engineered to extend hose assembly life
Hose Inner Diameter | 1-1/2 |
Hose Outer Diameter | 2-5/64 |
Working Pressure | 150 |
Min Burst Pressure | 600 |
Min Bend Radius | 5 |
Vacuum Service | 25 |
Hose Weight | 85 |
Available Lengths | 150 |
Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
