Weatherhead FD86-1002-16-16 - Hansen and Gromelle Coupling - Coupling MHalf 5000PSI ROCKB
- Part Number
- FD86-1002-16-16
- Manufacturer
- WEATHERHEAD
- Description
-
Hansen and Gromelle Coupling - Coupling MHalf 5000PSI ROCKB
details
$28849
MSRP: $757.99
Save: $469.50
Limited Availability
. Learn more
WEATHERHEAD part description
| A in | 4.4 |
| Air Inclusion (cc. max) | 2.9 |
| B in | 2.11 |
| Coupling Size | 16 |
| Coupling Type | Male |
| Description | Female NPT |
| Dust Cap (Buna-N) | FD86-1018-16 |
| Dust Plug (Buna-N) | FD86-1016-16 |
| Family | FD86 Series |
| Fig. | 1 |
| Fluid Loss (cc. max) | 0.72 |
| Hex1 (in) | 1.75 |
| Max. Operating Pressure (Connected)- Hydraulic (ps | 5000 |
| Min. Burst Pressure- Connected (psi) | 15000 |
| Port/Tube Outside Diameter Size | 16 |
| Rated Flow (gpm) | 50 |
| Repair Kit-Part number (Buna-N) | FF10596-16 |
| Repair Kit-Part number (EPR) | FF10598-16 |
| Repair Kit-Part number (Viton) | FF10597-16 |
| Sub-Title | Thread to Connect 5,000 psi Dry Break - High Impulse |
| Thread (P) | 1-11 1/2 |
| Type | Female NPT |
| Vacuum (Connected only ) (in./Hg) | 28 |
Eaton’s FD86 Series is a thread together steel quick coupling offering dry break and high impulse technology and capabilities. The maximum operating pressure is 5,000 psi. The FD86 Series is available in either wing nut or hex nut configurations for ease of assembly and disassembly.
Features & Benefits
- Thread together and tubular valve and sleeve construction
- Connection and disconnection against pressures up to 750 psi
- PTFE back-up rings along with secondary metal-to-metal sealing contact provides high impulse capability up to 5,000 psi operating pressure
- Steel flange available for bulkhead mounting
- Standard seal material: Nitrile
- Standard body material: High resistance carbon steel with zinc trivalent plating
Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
