(888) 312-8812 Login SignupCLOYES 95534 Engine Timing Chain Tensioner Guide
MSRP: $24.66
$1949
Save $5.17
Limited availability at this price!
In Stock
Get it by Monday, Jan 12
CLOYES 95534 Part Description
Manufacturer
Product Description
Engine Timing Chain Tensioner Guide
Features & Benefits
- Extensively tested and measured for function, fitment, and durability to ensure optimal performance
- A timing chain guide serves as a track or guide, for the timing chain, connecting the crankshaft and camshaft. Designed to meet or exceed OEM performance requirements, Timing Guides, which are available in kits or as a stand-alone product, utilize the latest in design and material technology, ensuring quiet and maintenance-free experience
- CAD designed and manufactured using premium materials
- Recommended that the chain tensioner(s), sprocket(s), and guide(s) also be replaced when the chain is replaced, as these components play a vital role in system stability and accurate timing
- Refer to our online catalog for detailed application-specific information
CLOYES 95534 Specifications
Product Attributes
| Mounting Hole Quantity | 1 |
| Width (uom:in) | 1.00" IN |
| Bolts Included | No |
| Bracket Included | Yes |
| Activation Type | N/A |
| Adjustable | N/A |
| Color | Yellow/Black |
| Height | 1.88" in |
| Material | Nylon |
| Mount Hole Diameter | 0.52" IN |
| Outside Diameter | N/A IN |
| Spring Included | N/A |
| Type | Tensioner Guide |
| Universal Or Specific Fit | Specific |
| Length | 6 3/4" IN |
| Manually Adjustable | No |
| Pulley Included | N/A |
| Shoe Included | Yes |
| Mounting Bracket Included | Yes |
| Mounting Hole Quantity | 13.208 MM |
| Mounting Hole Diameter (uom:in) | 0.52" IN |
| Width (uom:mm) | 25.4 MM |
| Height (uom:mm) | 47.752 MM |
| Height (uom:in) | 1.88" IN |
| Length | 171.45 MM |
| CHAIN TYPE | Tensioner Guide |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708998180 |
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| UPC | 00750385811936 |
| UNSPSC | 26101900 |
CLOYES 95534 Part Interchanges
| Brand | Part Number |
|---|---|
| General Motors | 12623513 |
| NAPA Timing Products | 95534 |
| GMC | 12586960 |
| Cadillac | 12586960 |
| Saturn | 12586960 |
| Chevrolet | 12586960 |
| Buick | 12586960 |
| Pontiac | 12586960 |
CLOYES 95534 Fits Vehicles
- Cadillac CT4 (2022)
- GMC Acadia Limited (2017)
- GMC Canyon (2015-2016)
- Chevrolet Impala Limited (2014-2016)
- Chevrolet Colorado (2013-2016)
- Cadillac ATS (2013-2019)
- Cadillac XTS (2013-2019)
- Chevrolet Caprice (2012-2017)
- Saab 9-4X (2011)
- Chevrolet Captiva Sport (2008-2015)
- Chevrolet Impala (2012-2020)
- Saab 9-5 (2010-2011)
- Alfa Romeo Spider (2007-2008)
- Alfa Romeo GT (2007)
- Alfa Romeo Brera (2007-2008)
- GMC Terrain (2010-2017)
- Chevrolet Camaro (2010-2015)
- Suzuki Grand Vitara (2009-2010)
- Chevrolet Traverse (2009-2022)
- Pontiac G8 (2008-2009)
- Pontiac Torrent (2008-2009)
- Chevrolet Malibu (2008-2012)
- Chevrolet Equinox (2008-2017)
- Saturn Vue (2008-2010)
- Buick Enclave (2008-2022)
- GMC Acadia (2007-2016)
- Saturn Outlook (2007-2010)
- Buick Allure (2005-2008, 2010)
- Saturn Aura (2007-2009)
- Suzuki XL-7 (2007-2009)
- Cadillac SRX (2004-2016)
- Pontiac G6 (2007-2009)
- Saab 9-3 (2006-2009)
- Cadillac STS (2005-2011)
- Buick LaCrosse (2005-2008, 2010-2016)
- Cadillac CTS (2004-2019)
- Buick Rendezvous (2004-2006)
