Weatherhead 16U-G76 - Fitting - 90 Degree Hose End Code 61
- Part Number
- 16U-G76
- Manufacturer
- WEATHERHEAD
- Description
-
Fitting - 90 Degree Hose End Code 61
details
$3449
MSRP: $75.86
Save: $41.37
In stock
limited availability at this price!
. Learn more
WEATHERHEAD part description
Product Specifications
| End Type | Code 61 Flange |
| Hose Family | DIN 1S/SAE R1 |
| Hose Size | 16 |
| Material | Carbon Steel |
| Product Line | Weatherhead |
| Shape | 90 |
| Style | Permanent |
| A | 5.43 |
| Application | General purpose low, medium, and high pressure hydraulic. |
| B | 2.38 |
| Description | Split Flange 90 Tube Elbow |
| Dia "G" | 1.75 |
| Family | Coll-O-Crimp |
| Hole Dia | 0.76 |
| Hose Cut-Off Factor "D" | 3.23 |
| Hose ID | 1 |
| Nominal Flange Size | 1 |
| Plating | Zinc; yellow dichromate finish |
| Product Type | Fitting |
| Replacement O'ring (Not Included) | 16x252 |
| Series | U? Series |
| T | 0.32 |
Eaton Weatherhead U-Series Hose Fitting
Manufactured using high-quality materials, the Eaton Weatherhead hose fitting meets SAE, DOT, and all applicable industry standards. This component is ideal for use in low, medium, and high-pressure hydraulic applications.
Features & Benefits
- Premium-quality Coll-O-Crimp® "U" series hydraulic fitting
- Carbon steel construction with zinc dichromate finish for excellent corrosion resistance
- Can be used for on-site repair and maintenance of machines
- Meticulously tested to withstand high pressures and ensure leak-free performance
- Compatible with molders, mobile equipment, presses, as well as with general industrial hydraulic applications
Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
