(888) 312-8812 Login SignupDAYCO PB1264N PREMIUM OEM REPL BALANCER, POWERBOND
Tap to view 4 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
DAYCO PB1264N Part Description
DAYCO PB1264N Specifications
Product Attributes
| Overall Outside Diameter | 5.827 in |
| Overall Outside Diameter | 148.00 mm |
| Crank Bore | 1.339 in |
| Crank Bore | 34.01 mm |
| Overall Width | 2.245 in |
| Overall Width | 57.00 mm |
| Nose Outside Diameter | 1.812 in |
| Nose Outside Diameter | 46.00 mm |
| Ring Width | 1.278 in |
| Ring Width | 32.44 mm |
| Bolt Hole Quantity | 2 |
| Crank Trigger/Exciter Plate | No |
| Woodruff Key Included | No |
| Hardware Included | No |
| Counterweight Balance | Neutral, no counterweight |
| Timing Marks | Yes |
| Installation Instructions Included | No |
| Number of Integrated Pulleys | 3 |
| Pulley 1 Type | V-Belt |
| Pulley 1 Outside Diameter | 5.827 in |
| Pulley 1 Outside Diameter | 148.000 mm |
| Pulley 1 Number Of Grooves | 1 mm |
| Pulley 2 Type | V-Belt |
| Pulley 2 Outside Diameter | 5.827 in |
| Pulley 2 Outside Diameter | 148.000 mm |
| Pulley 2 Number Of Grooves | 1 mm |
| Outer Ring Material | Cast Iron |
Additional Information
| Country of Origin (Primary) | AU |
| Harmonized Tariff Code (Schedule B) | 8483509080 |
| UPC | 09317010001110 |
DAYCO PB1264N Part Interchanges
| Brand | Part Number |
|---|---|
| DORMAN | 594-811, NA |
| ATP | NA |
| NAPA | NA |
| PIONEER | NA |
DAYCO PB1264N Fits Vehicles
- Mazda MPV (1989-1994)
- Mazda B2600 (1989-1993)
