WEATHERHEAD part description

Angle Shape Straight
Application General purpose low and medium pressure hydraulics. Use H277 or H435 where shock hazards exist
Compatible Hose ID 0.75 inch
Compatible Hoses H104, H145, H145R, H190, H190H, H245, H245L, H280, H290, H290H, H290L, H345, H350, H400, H421, H425, H1777 (-04, -06, 08), H1776 (-04 thru -20), H1571 (-12 only), H6002 (-08, -12, -16), H6008 (-16 & -20), H6009 (-20 only), H9622 (-12, -16, -20), H265 (-04, -06, -08, -12, -16), H275 (-04 thru -16), H1812 (-04 thru -20), H0106 (-04 thru -10), H0105 (-06 thru -12, -20), H116 (-04, -06, -08), H115 (-04 thru -20), H1982 (-06 thru -16), H1981 (-04, -06, -08), H9949, EC115, EC215, EC110, EC210, EC118
Construction Style Crimp
End Size 1 3/4 IN
End Gender 1 Female
End Type 1 Metric
End Type 2 Line/Hose/Tube
Finish Plating Dura-Kote
Hex Size 1 1.81 inch
Hose Cut Off Factor 1.64 inch
Hose Dash Size -12
InsIDe Diameter 0.61 inch
Item Type Fitting Assembly
PrODuct Material Carbon steel
Thread Size 1 M36X2
Thread Sealant No

Features & Benefits

  • Dura-Kote plating for superior corrosion resistance
  • Innovative design to deliver performance and maximum uptime
  • System engineered to extend hose assembly life
  • Over 550 Z-Series part numbers available
  • Eaton’s WeatherMATCH program provides identification markings on the hose, hose fittings, and crimp dies for quick and easy assembly
  • Eaton’s best selling one-piece bite the wire style hose fitting that is qualified with virtually all Weatherhead one and two braided hydraulic hoses.

Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
