Name: Sealed Power L-2320F 30 "Speed Pro" POWERFORGED Engine Piston Set
SKU: l2320f30
Price: 811.92 USD
Availability: InStock

SEALED POWER part description

Product Description

Engine Piston Set

Application Summary

1968 Oldsmobile Delmont 88 (Liter: 5.7 & Engine(cc): 5733 & Engine(ci): 350 & Cylinder: 8 & Block: V & Bore(in): 4.06, 3.88 & Bore(mm): 103.0, 98.4 & Stroke(in): 3.39, 3.75 & Stroke(mm): 86.0, 95.3); 1968-1971 Oldsmobile F85 (Liter: 5.7 & Engine(cc): 5733 & Engine(ci): 350 & Cylinder: 8 & Block: V & Bore(in): 4.06, 3.88 & Bore(mm): 103.0, 98.4 & Stroke(in): 3.39, 3.75 & Stroke(mm): 86.0, 95.3); 1968-1971 Oldsmobile Cutlass (Liter: 5.7 & Engine(cc): 5733 & Engine(ci): 350 & Cylinder: 8 & Block: V & Bore(in): 4.06, 3.88 & Bore(mm): 103.0, 98.4 & Stroke(in): 3.39, 3.75 & Stroke(mm): 86.0, 95.3); 1968-1971 Oldsmobile Cutlass Supreme (Liter: 5.7 & Engine(cc): 5733 & Engine(ci): 350 & Cylinder: 8 & Block: V & Bore(in): 4.06, 3.88 & Bore(mm): 103.0, 98.4 & Stroke(in): 3.39, 3.75 & Stroke(mm): 86.0, 95.3); 1968-1971 Oldsmobile Delta 88 (Liter: 5.7 & Engine(cc): 5733 & Engine(ci): 350 & Cylinder: 8 & Block: V & Bore(in): 4.06, 3.88 & Bore(mm): 103.0, 98.4 & Stroke(in): 3.39, 3.75 & Stroke(mm): 86.0, 95.3); 1968-1971 Oldsmobile Vista Cruiser (Liter: 5.7 & Engine(cc): 5733 & Engine(ci): 350 & Cylinder: 8 & Block: V & Bore(in): 4.06, 3.88 & Bore(mm): 103.0, 98.4 & Stroke(in): 3.39, 3.75 & Stroke(mm): 86.0, 95.3)

Features & Benefits

Forged under 3,000 tons of force.
Fully updated skirt profiles
Exclusive DUROSHIELD(R) skirt coating. DUROSHIELD(R) provides scuff resistance, reduced bore clearances and enhanced ring sealing.
SPEED-PRO(R) POWERFORGED(R) pistons are built to stringent specifications with a precision CNC-machined dome and skirts and microfinished ring grooves.
The manufacturing process ensures that piston weights within a boxed set will not vary more than 4 grams and that skirt sizes are matched to within 0.016mm (0.0006") per set.
Machined valve reliefs and circlip grooves; LR-63 lock rings for floated applications

Product Attributes

Oversized	Yes
Top Compression Ring Thickness	0.0781 IN
Second Compression Ring Thickness	0.0781 IN
Oil Ring Thickness	0.1875 IN
Assembly Lubricant Included	No
Bore Diameter	4.087 IN
Piston Material	POWERFORGED(R)
9607	1.612 IN
Dome Volume CC	0.0
Head Illustration	23
Head Type	Flat; DUROSHIELD skirt coated piston
Lock Ring	N/R
Minimum Clearance	.0025
Oversize Inch	.030
Part Description	Engine Piston
Pin Diameter (Inch)	0.980
Pin Type	P
Pin Weight Gram	194
Weight W Pin Gram	849
Weight w/o Pin Gram	655

Additional Information

Country of Origin (Primary)	IN
Canadian Harmonizing Tariff Code	8409910010
Harmonized Tariff Code (HTS)	8409915085
UPC	00087674134262

Part Interchanges

Speed-Pro® is the go-to brand not only for racers and performance enthusiasts but also for those who are cruising down the road day in day out. With its engineering expertise, advanced technologies, and industry-leading manufacturing facilities and techniques, Speed-Pro sets the bar higher for other manufacturers of pistons, engine bearing parts, and performance engine components. The engine solutions from Speed-Pro are meticulously designed and crafted to boost horsepower production and make engine rebuild an easy feat. Since its establishment, this brand has continuously improved and refined its operations and quality control measures to maintain high quality standards and satisfy customers’ requirements and demands.

Fits Vehicles

Oldsmobile Delmont 88 (1968)
Oldsmobile Cutlass Supreme (1968-1971)
Oldsmobile Vista Cruiser (1968-1971)
Oldsmobile Delta 88 (1968-1971)
Oldsmobile Cutlass (1968-1971)
Oldsmobile F85 (1968-1971)
