Sealed Power H580CP60 - Sealed Power H580CP 60 Engine Piston Set
- Part Number
- H580CP60
- Manufacturer
- SEALED POWER
- Description
-
Sealed Power H580CP 60 Engine Piston Set
details
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
SEALED POWER part description
Product Description
Engine Piston Set
Features & Benefits
- Helps improve cylinder sealing for less blow-by
- Retains standard ring gaps in top groove
- DUROSHIELD(R) skirt-coated piston
- DUROSHIELD® skirt-coated piston
- Moly-graphite coating extends engine life
- Reduces friction for higher fuel economy
- Prevents damage from inadequate lubrication on start-up
Product Attributes
| Oversized | Yes |
| Top Compression Ring Thickness | 0.0781 IN |
| Second Compression Ring Thickness | 0.0781 IN |
| Oil Ring Thickness | 0.1875 IN |
| Piston Pin Outside Diameter | 0.9275 IN |
| Assembly Lubricant Included | No |
| Bore Diameter | 4.0000 IN |
| Piston Material | Hypereutectic |
| 9607 | 1.550 IN |
| Head Illustration | 187 |
| Head Type | Recessed Head .185 deep x 3.300 dia. w/2 valve reliefs; DUROSHIELD~ skirt coated piston |
| Minimum Clearance | See Piston Fitting Information on carton label |
| Oversized Amount | 0.060 IN |
| Part Description | Engine Piston |
| Pin Offset (Inch) | 0.06 |
| Pin Offset (MM) | 1.524 |
| Pin Type | P |
| Weight W Pin Gram | 00710.+/- 00. |
| Bore Diameter | 101.6 MM |
| Grade Type | Premium |
| Piston Pin Outside Diameter | 23.559 MM |
Additional Information
| Country of Origin (Primary) | IN |
| Canadian Harmonizing Tariff Code | 8409910010 |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Harmonized Tariff Code (HTS) | 8409915085 |
| UPC | 00614046627437 |
Part Interchanges
- Badger P600-060
- TRW Steering and Suspension Parts L3084F60
- Clevite 9-1487.060
- Ertel 1331P60
- ZH8269C 060
- Z8101D 060
- Dana Commercial Vehicle Service Parts 224-1845.060
- Dana Commercial Vehicle Service Parts TC1845.060
- Dana Commercial Vehicle Service Parts TC2745A.060
- Dana Commercial Vehicle Service Parts 224-2745.060
- Dana Commercial Vehicle Service Parts TC2745.060
- Badger P600060
- Clevite 91487060
- Sealed Power 9148P60
- Zollner Z8101D060
- Zollner ZH8269C060
- Dana Commercial Vehicle Service Parts 2241845060
- Dana Commercial Vehicle Service Parts 2242745060
- Dana Commercial Vehicle Service Parts TC1845060
- Dana Commercial Vehicle Service Parts TC2745060
- Dana Commercial Vehicle Service Parts TC2745A060
Fits Vehicles
- GMC P3500 (1991-1995)
- GMC G3500 (1991-1995)
- GMC C7000 (1979)
- GMC P6000 (1984-1990)
- Chevrolet P60 (1983-1990)
- GMC B6000 (1980-1990)
- Chevrolet B60 (1980-1990)
- Chevrolet C70 (1979, 1986)
- GMC C6000 (1979-1990)
- GMC C5000 (1979-1990)
- Chevrolet C60 (1972-1990)
- Chevrolet C50 (1972-1990)
- Chevrolet P30 (1991-1995)
- Chevrolet G30 (1991-1995)
