A-1 Cardone 27-7515 - Steering Gear
- Part Number
- 27-7515
- Manufacturer
- A-1 CARDONE
- Description
-
Steering Gear
details
$14899
+$45.60 Core Deposit
Total price w/ core: $194.59
5 day lead time
limited availability at this price!
. Learn more
A-1 CARDONE part description
Product Description
Steering Gear
Application Summary
Dodge D100 1979-78, D150 1979-78, D200 1979-78, D300 1979-78, D400 1979-78, D450 1979-78, Ramcharger 1979-78, W150 1979-78, W200 1979-78, W300 1979-78; Plymouth Trailduster 1979-78
Features & Benefits
- 100% hydraulic testing measures for proper flow, leakage and performance to ensure perfect fit and function.
- 100% new O-rings and lip seals ensure leak-free, long-lasting performance.
- All critical components are tested to ensure product reliability.
- Shafts are surfaced to precise specifications to eliminate premature seal wear and extend gear life.
- Rust inhibitive "Cool Dip" finish is a penetrating dye that completely covers all exposed surfaces for a consistent, protective finish that will not crack, flake or peel.
- As a remanufactured Original Equipment part, this unit guarantees a perfect vehicle fit.
- Our remanufacturing process is earth-friendly, as it reduces the energy and raw material needed to make a new part by 80%.
Power Steering Gear, Steering Gear, Gear Box
Product Attributes
| Color | Black |
| Package Contents | Gear; Instruction Sheet; Instruction Tag |
| Product Condition | Remanufactured |
| Input Shaft Spline Count | 25 |
| Number of Mounting Holes | 4 |
| Hose Port Type | Seat |
| Total Turns Lock to Lock | 4.13 |
| Pressure Port Thread Size | 11/16-18 |
| Return Port Thread Size | 5/8-18 |
| Pump Rotation | Reverse |
| Pitman Arm Included | No |
| Input Shaft Type | Splined;Single Flat |
| Steering Box Type | Power |
| E-waste | No |
| Input Shaft Diameter (in) | 0.787 |
| Input Shaft Diameter (mm) | 19.99 |
| Output Shaft Diameter (mm) | 21.95 |
| Output Shaft Diameter (in) | 0.864 |
| Features and Benefits | Shafts are surfaced to precise specifications to eliminate premature seal wear and extend gear life. |
| Hose Port Type | Seat |
| Input Shaft Diameter | 0.787 IN |
| 465 | 19.9898 MM |
| Input Shaft Spline Quantity | 25 |
| Mounting Hardware Included | No |
| 2313 | 31.75 MM |
| 2313 | 1.25 IN |
| Output Shaft Spline Quantity | 32 |
| 6523 | 21.95 MM |
| 6523 | 0.864 IN |
| Power Assisted | Yes |
| 9605 | 17.45 MM |
| 9605 | 0.687 IN |
| 9604 | 11/16-18 |
| 9606 | 0.618 IN |
| 9606 | 15.7 MM |
| 9603 | 5/8-18 |
| Total Turns Lock To Lock | 4.13 |
| Type | Power |
| Splined Input Shaft | Yes |
| FAQ_Q1 | Should the power steering hoses be replaced? |
| FAA_A1 | Hoses should be replaced if they appear brittle or if there are any kinks or leaks. |
| FAQ_Q2 | What is the difference between a fast ratio and a slow ratio gear box? |
| FAA_A2 | The difference is the orientation of the teeth on the pitman shaft and power piston. Variable teeth will have a faster ratio than non-variable teeth. |
| FAQ_Q3 | How can I tell if my gear box is a standard or reverse rotation? |
| FAA_A3 | In a standard rotation gear box, the input and pitman shaft rotate in the same direction. The shafts turn in opposite directions on a reverse rotation gear box. |
| FAQ_Q4 | Can I adjust my original gear box if it has a lot of play? |
| FAA_A4 | Not recommended. The preload is adjusted at the time of assembly. If excessive play is present, it’s due to wear of internal components. If adjustment is attempted, it could lead to binding. |
| Contains Electronic Components | No |
| Does it require SDS | No |
| Is Item A Chemical | No |
| Is Or Contains A Battery | No |
| Is Or Contains A Bulb | No |
| Is Prop Sixty Five Affected | No |
| Is the item CARB affected | No |
Additional Information
| Remanufactured Part | Y |
| Warranty Distance | 36000 |
| Warranty Distance UOM | DH |
| Warranty Special UOM | TX |
| Warranty Time | 36 |
| Warranty Time UOM | MO |
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8708948000 |
| Harmonized Tariff Code (HTS) | 8708945000 |
| Canadian Harmonizing Tariff Code | 8708949900 |
| UPC | 00082617027007 |
Fits Vehicles
- Plymouth Trailduster (1978-1979)
- Dodge W300 (1978-1979)
- Dodge W200 (1978-1979)
- Dodge W150 (1978-1979)
- Dodge Ramcharger (1978-1979)
- Dodge D450 (1978-1979)
- Dodge D400 (1978-1979)
- Dodge D300 (1978-1979)
- Dodge D150 (1978-1979)
- Dodge D200 (1978-1979)
- Dodge D100 (1978-1979)
