Centric 123.44040 - C-Tek Standard Brake Drum
$3249
MSRP: $34.86
Save: $2.37
In stock
limited availability at this price!
Pay over 3-12 months with . Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
Misc Holes [cntrc] | 2 |
Weight [cntrc] Kgs | 4.659 |
Weight [cntrc] Lbs | 10.250 |
Mounting Type [cntrc] | Floating |
Bolt Circle Diameter [cntrc] Mm | 100.000 |
Bolt Circle Diameter [cntrc] In | 3.937 |
Hub Hole / Register [cntrc] Mm | 55.110 |
Hub Hole / Register [cntrc] In | 2.170 |
Height [cntrc] Mm | 51.800 |
Height [cntrc] In | 2.039 |
Friction Surface Width [cntrc] Mm | 41.150 |
Friction Surface Width [cntrc] In | 1.620 |
Product Grade [cntrc] | Standard |
Maximum Brake Diameter (Discard) | 201.000 MM |
Maximum Brake Diameter (Discard) | 7.913 IN |
Bolt Hole Quantity | 4 |
Outside Diameter | 233.000 MM |
Outside Diameter | 9.173 IN |
Outer Cooling Fins | No |
Mounting Hole Diameter | 14.800 MM |
Mounting Hole Diameter | 0.583 IN |
Nominal Drum Diameter | 200.000 MM |
Nominal Drum Diameter | 7.874 IN |
Additional Information
Harmonized Tariff Code (HTS) | 8708305030 |
Harmonized Tariff Code (Schedule B) | 8708300050 |
NAFTA Preference Criterion Code | B |
Country of Origin (Primary) | CN |
UPC | 805890076308 |
Part Interchanges
CENTRIC 123.44040 Cross Reference
We have 1 alternatives for the 123.44040 by CENTRIC:
Fits Vehicles
- Scion xA (2004-2006)
- Toyota Yaris (2004-2006)
- Scion xB (2004-2006)
- Toyota Prius (2001-2003)
