CENTRIC part description

Product Description

C-Tek Standard Brake Rotor

Features & Benefits

  • Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket

Product Attributes

Disc Mounting [cntrc] Floating
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Weight [cntrc] Kgs 11.820
Vane Style [cntrc] Straight
Misc Holes [cntrc] 0
Weight [cntrc] Lbs 26.000
Product Grade [cntrc] Standard
Discard Thickness 28.500 MM
Discard Thickness 1.122 IN
Nominal Thickness 1.181 IN
Nominal Thickness 30.000 MM
Overall Height 2.126 IN
Overall Height 54.000 MM
Outside Diameter 330.000 MM
Outside Diameter 12.992 IN
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Vented
Bearings Included No
Center Hole Diameter 3.551 IN
Center Hole Diameter 90.200 MM
Mounting Bolt Hole Circle Diameter 135.000 MM
Mounting Bolt Hole Circle Diameter 5.315 IN
Stud/Lug Hole Quantity 6
Stud/Lug Hole Diameter 0.602 IN
Stud/Lug Hole Diameter 15.300 MM

Additional Information

Harmonized Tariff Code (Schedule B) 8708300050
Harmonized Tariff Code (HTS) 8708305030
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
UPC 805890230441

Part Interchanges

CENTRIC 121.65100 Cross Reference

We have 4 alternatives for the 121.65100 by CENTRIC:

Fits Vehicles

  • Lincoln Mark LT (2006-2008)
  • Ford F-150 (2004-2008)
