Centric 123.63015 - C-Tek Standard Brake Drum
$10849
MSRP: $143.64
Save: $35.15
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Weight [cntrc] Kgs | 13.159 |
| Weight [cntrc] Lbs | 28.950 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 101.600 |
| Bolt Circle Diameter [cntrc] In | 4.000 |
| Hub Hole / Register [cntrc] Mm | 58.674 |
| Hub Hole / Register [cntrc] In | 2.310 |
| Height [cntrc] Mm | 117.094 |
| Height [cntrc] In | 4.610 |
| Friction Surface Width [cntrc] Mm | 73.152 |
| Friction Surface Width [cntrc] In | 2.880 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 256.300 MM |
| Maximum Brake Diameter (Discard) | 10.090 IN |
| Bolt Hole Quantity | 5 |
| Nominal Drum Diameter | 10.000 IN |
| Nominal Drum Diameter | 254.000 MM |
| Mounting Hole Diameter | 0.560 IN |
| Mounting Hole Diameter | 14.224 MM |
| Outer Cooling Fins | Yes |
| Outside Diameter | 12.400 IN |
| Outside Diameter | 314.960 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890977827 |
Part Interchanges
CENTRIC 123.63015 Cross Reference
We have 1 alternatives for the 123.63015 by CENTRIC:
Fits Vehicles
- Plymouth Scamp (1973-1975)
- Plymouth Valiant (1973-1976)
- Plymouth Duster (1973-1975)
- Dodge Dart (1973-1976)
