Centric 123.42010 - C-Tek Standard Brake Drum
$5599
MSRP: $61.85
Save: $5.86
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Weight [cntrc] Kgs | 7.614 |
| Weight [cntrc] Lbs | 16.750 |
| Mounting Type [cntrc] | Behind the Hub |
| Bolt Circle Diameter [cntrc] Mm | 170.200 |
| Bolt Circle Diameter [cntrc] In | 6.701 |
| Hub Hole / Register [cntrc] Mm | 139.950 |
| Hub Hole / Register [cntrc] In | 5.510 |
| Height [cntrc] Mm | 115.570 |
| Height [cntrc] In | 4.550 |
| Friction Surface Width [cntrc] Mm | 67.560 |
| Friction Surface Width [cntrc] In | 2.660 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 221.500 MM |
| Maximum Brake Diameter (Discard) | 8.720 IN |
| Bolt Hole Quantity | 6 |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 16.800 MM |
| Mounting Hole Diameter | 0.661 IN |
| Nominal Drum Diameter | 219.700 MM |
| Nominal Drum Diameter | 8.650 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890914624 |
Part Interchanges
CENTRIC 123.42010 Cross Reference
We have 2 alternatives for the 123.42010 by CENTRIC:
Fits Vehicles
- Nissan D21 (1986-1987)
