CENTRIC part description

Product Description

C-Tek Semi-Metallic Brake Pads with Shims

Features & Benefits

  • Shimmed to eliminate noise and vibration. Formulated for reduced noise. Semi-Metallic compounds. Post cured for consistent performance throughout the service life of the brake pad. 100% Asbestos and Copper free formulas.

Product Attributes

Weight [cntrc] Lbs 6.50
Weight [cntrc] Kgs 2.95
Hardware Kit Number [cntrc] 117.67001
Notes01 [cntrc] 2 Pads with 1 Wear Sensor
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Product Grade [cntrc] Standard
Pad Wear Sensor Included Yes
Friction Material Composition Semi-Metallic
Mounting Hardware Included No
Pad Shims Included Yes
Friction Material Attachment Integrally Molded
Pad Quantity 4
Prepared For Pad Wear Sensor Yes
Outer Pad Height 70.000 MM
9433 2.756 IN
Inner Pad Height 65.500 MM
Inner Pad Height 2.579 in
Outer Pad Width 206.300 MM
9435 8.122 IN
Inner Pad Width 182.900 MM
Inner Pad Width 7.201 in
9478 16.000 MM
9478 0.630 in
9479 20.000 MM
9479 0.787 IN

Additional Information

NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
Harmonized Tariff Code (HTS) 8708305090
UPC 805890058861

Part Interchanges

Fits Vehicles

  • International 200 (1974-1975)
  • International Travelall (1975)
  • Workhorse P42 (1999-2005)
  • Workhorse P32 (1999-2005)
  • GMC P4500 (1983-1987)
  • Chevrolet P40 (1983, 1985-1987)
  • Chevrolet P30 Van (1971-1974)
  • Chevrolet K30 Pickup (1973-1974)
  • Chevrolet G30 Van (1974)
  • Chevrolet C30 Pickup (1974)
  • Chevrolet R3500 (1989-1991)
  • Chevrolet R30 (1987-1988)
  • GMC V3500 (1987-1991)
  • Chevrolet K30 (1977-1986)
  • GMC R3500 (1987-1991)
  • Chevrolet G30 (1975-1995)
  • GMC P3500 (1979-1999)
  • GMC P35 (1975-1978)
  • GMC K3500 (1979-1986)
  • GMC K35 (1977-1978)
  • GMC C3500HD (1991-1994)
  • Chevrolet C3500HD (1991-1994)
  • Dodge W350 (1981-1993)
  • Dodge W300 (1975-1980)
  • Dodge W250 (1986-1993)
  • Dodge W200 (1975-1979)
  • GMC G3500 (1979-1995)
  • GMC G35 (1975-1978)
  • Chevrolet C30 (1975-1986)
  • Chevrolet P30 (1975-1999, 2001-2002)
  • Chevrolet C35 (1983-2000)
  • GMC P35/P3500 Van (1971-1974)
  • GMC K35/K3500 Pickup (1973-1974)
  • GMC G35/G3500 Van (1974)
  • GMC C35/C3500 Pickup (1974)
  • GMC C3500 (1979-1986)
  • GMC C35 (1975-1978)
  • Workhorse P30 (2000-2005)
  • Dodge W300 Pickup (1974)
  • Chevrolet V3500 (1989-1991)
  • Chevrolet V30 (1987-1988)
