Centric 121.65141 - C-Tek Standard Brake Rotor
$9799
MSRP: $148.59
Save: $50.60
In stock
limited availability at this price!
Pay over 3-12 months with . Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
Vane Style [cntrc] | Straight |
Misc Holes [cntrc] | 0 |
Hat Id [cntrc] In | 8.870 |
Max Pb Drum Dia [cntrc] In | 9.102 |
Weight [cntrc] Lbs | 39.250 |
Disc Mounting [cntrc] | Behind the Hub |
California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
Hat Id [cntrc] Mm | 225.300 |
Max Pb Drum Dia [cntrc] Mm | 231.200 |
Weight [cntrc] Kgs | 17.820 |
OEM Vane Count [cntrc] | 53 |
Product Grade [cntrc] | Standard |
Discard Thickness | 36.400 MM |
Discard Thickness | 1.433 IN |
Nominal Thickness | 38.000 MM |
Nominal Thickness | 1.496 IN |
Overall Height | 126.300 MM |
Overall Height | 4.972 IN |
Outside Diameter | 363.000 MM |
Outside Diameter | 14.291 IN |
Mounting Bolt Hole Quantity | 8 |
ABS Tone Ring Included | No |
Surface Type | Smooth |
Solid Or Vented Type Rotor | Vented |
Nominal Drum Diameter | 229.700 MM |
Nominal Drum Diameter | 9.043 IN |
Bearings Included | No |
Center Hole Diameter | 127.500 MM |
Center Hole Diameter | 5.020 IN |
Mounting Bolt Hole Circle Diameter | 155.400 MM |
Mounting Bolt Hole Circle Diameter | 6.118 IN |
Mounting Bolt Hole Diameter | 12.800 MM |
Mounting Bolt Hole Diameter | 0.504 IN |
Additional Information
Harmonized Tariff Code (Schedule B) | 8708300050 |
NAFTA Preference Criterion Code | B |
Country of Origin (Primary) | CN |
Harmonized Tariff Code (HTS) | 8708305030 |
UPC | 805890964209 |
Part Interchanges
CENTRIC 121.65141 Cross Reference
We have 2 alternatives for the 121.65141 by CENTRIC:
Fits Vehicles
- Ford F-450 Super Duty (2013-2016)
- Ford F-350 Super Duty (2012-2020, 2022)
