Centric 122.62000 - Centric Premium Brake Drum
$6649
MSRP: $73.16
Save: $6.67
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
Product Attributes
| Misc Holes [cntrc] | 5 |
| Weight [cntrc] Kgs | 6.818 |
| Weight [cntrc] Lbs | 15.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 120.650 |
| Bolt Circle Diameter [cntrc] In | 4.750 |
| Hub Hole / Register [cntrc] Mm | 71.628 |
| Hub Hole / Register [cntrc] In | 2.820 |
| Height [cntrc] Mm | 77.978 |
| Height [cntrc] In | 3.070 |
| Friction Surface Width [cntrc] Mm | 59.944 |
| Friction Surface Width [cntrc] In | 2.360 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 281.700 MM |
| Maximum Brake Diameter (Discard) | 11.090 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 313.944 MM |
| Outside Diameter | 12.360 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 11.430 MM |
| Mounting Hole Diameter | 0.450 IN |
| Nominal Drum Diameter | 279.400 MM |
| Nominal Drum Diameter | 11.000 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890045090 |
Part Interchanges
- Raybestos Brakes 2003
- Raybestos Brakes 2003R
- BD60001
- E127-67-005
- 8101
- 8101G
- 3828686
- 3828709
- 3868801
- 3869537
- 3974253
- 3985944
- 3738430
- 3752621
- 3752622
- 3755504
- 3696213
- 8738430
- 201010
- PDR0022
- 140022
- 6401060
- 800
- AD8200
- D2003
- E12767005
- 712003
- 87000
- YH140022
- 23063
- X21008
- BD1033
- 8836000
- 17720
- 18B382
- 36547007
CENTRIC 122.62000 Cross Reference
We have 2 alternatives for the 122.62000 by CENTRIC:
Fits Vehicles
- Jeep DJ5 (1978-1981)
- Chevrolet Corvair Truck (1961-1964)
- Chevrolet Parkwood (1959-1961)
- Chevrolet Yeoman (1958)
- Chevrolet Nomad (1955-1961)
- Chevrolet Fleetline (1951-1952)
- GMC G15/G1500 Van (1971)
- Chevrolet Two-Ten Series (1953-1957)
- Chevrolet Townsman (1969-1970)
- Chevrolet Styleline Deluxe (1951-1952)
- Chevrolet One-Fifty Series (1953-1957)
- Chevrolet Kingswood (1969-1970)
- Chevrolet Impala (1958-1970)
- Chevrolet G10 Van (1971)
- Chevrolet El Camino (1964-1965)
- Chevrolet Del Ray (1957-1958)
- Chevrolet Corvette (1953-1966)
- Chevrolet Chevelle (1965-1966)
- Chevrolet Caprice (1966-1970)
- Chevrolet Brookwood (1958-1961, 1969-1970)
- Chevrolet Biscayne (1958-1970)
- Chevrolet Bel Air (1951-1970)
