CENTRIC part description

Product Description

C-Tek Standard Brake Rotor

Features & Benefits

  • Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket

Product Attributes

Vane Style [cntrc] Straight
Misc Holes [cntrc] 1
Hat Id [cntrc] In 5.528
Weight [cntrc] Lbs 12.250
Product Grade [cntrc] Standard
Disc Mounting [cntrc] Floating
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Hat Id [cntrc] Mm 140.400
Weight [cntrc] Kgs 5.570
Discard Thickness 0.803 IN
Discard Thickness 20.400 MM
Stud/Lug Hole Diameter 0.638 IN
Stud/Lug Hole Diameter 16.200 MM
Stud/Lug Hole Quantity 4
Mounting Bolt Hole Circle Diameter 3.937 IN
Mounting Bolt Hole Circle Diameter 100.000 MM
Center Hole Diameter 2.520 IN
Center Hole Diameter 64.000 MM
Bearings Included No
Solid Or Vented Type Rotor Vented
Surface Type Smooth
ABS Tone Ring Included No
Outside Diameter 10.984 IN
Outside Diameter 279.000 MM
Overall Height 44.200 MM
Overall Height 1.740 IN
Nominal Thickness 0.858 IN
Nominal Thickness 21.800 MM

Additional Information

Harmonized Tariff Code (HTS) 8708305030
Harmonized Tariff Code (Schedule B) 8708300050
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
UPC 805890453130

Part Interchanges

CENTRIC 121.34100 Cross Reference

We have 3 alternatives for the 121.34100 by CENTRIC:

Fits Vehicles

  • Mini Cooper (2007-2015)
