CENTRIC part description

Product Description

C-Tek Standard Brake Rotor

Features & Benefits

  • Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket

Product Attributes

Disc Mounting [cntrc] Floating
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Weight [cntrc] Kgs 8.550
Vane Style [cntrc] Straight
Misc Holes [cntrc] 1
Weight [cntrc] Lbs 18.800
Product Grade [cntrc] Standard
Stud/Lug Hole Diameter 13.000 MM
Stud/Lug Hole Diameter 0.512 IN
Stud/Lug Hole Quantity 5
Mounting Bolt Hole Circle Diameter 114.300 MM
Mounting Bolt Hole Circle Diameter 4.500 IN
Center Hole Diameter 72.000 MM
Center Hole Diameter 2.835 IN
Bearings Included No
Solid Or Vented Type Rotor Vented
Surface Type Smooth
ABS Tone Ring Included No
Outside Diameter 11.614 IN
Outside Diameter 295.000 MM
Overall Height 2.020 IN
Overall Height 51.300 MM
Nominal Thickness 1.102 IN
Nominal Thickness 28.000 MM
Discard Thickness 26.000 MM
Discard Thickness 1.024 IN

Additional Information

Harmonized Tariff Code (Schedule B) 8708300050
Harmonized Tariff Code (HTS) 8708305030
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
UPC 805890198819

Part Interchanges

CENTRIC 121.45060 Cross Reference

We have 2 alternatives for the 121.45060 by CENTRIC:

Fits Vehicles

  • Mazda Millenia (2001-2002)
