CENTRIC part description

Product Description

Centric Premium Brake Drum with Bearing

Application Summary

Ford Focus 2011-2009

Features & Benefits

  • OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise

C-Tek; Centric; Standard brake rotor; Premium brake drum; Centric Premium Drums

Product Attributes

132 12 MM
Maximum Brake Diameter (Discard) 204.300 MM
Bolt Hole Quantity 4
Outside Diameter 240.000 MM
Outer Cooling Fins No
Nominal Drum Diameter 202.900 MM
Bolt Circle Diameter [cntrc] In 4.250
Bolt Circle Diameter [cntrc] Mm 107.950
Friction Surface Width [cntrc] In 1.772
Friction Surface Width [cntrc] Mm 45.000
Height [cntrc] In 3.201
Height [cntrc] Mm 81.305
Hub Hole / Register [cntrc] In 2.492
Hub Hole / Register [cntrc] Mm 63.300
Mounting Type [cntrc] Hub & Drum
Notes [cntrc] Bearing Included
Stud Thread Pitch [cntrc] Mm 1.50
Weight [cntrc] Kgs 7.705
Weight [cntrc] Lbs 16.950

Additional Information

Country of Origin (Primary) CN
Harmonized Tariff Code (Schedule B) 8708300050
Harmonized Tariff Code (HTS) 8708305030
NAFTA Preference Criterion Code B
UPC 00805890530930

Part Interchanges

CENTRIC 122.6105 Cross Reference

We have 2 alternatives for the 122.6105 by CENTRIC:

Fits Vehicles

  • Ford Focus (2009-2011)
