CENTRIC part description

Product Description

C-Tek Standard Brake Rotor

Features & Benefits

  • Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket

Product Attributes

Outer Race # [cntrc] 416.66000
Product Grade [cntrc] Standard
Inner Seal # [cntrc] 417.66008
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Weight [cntrc] Lbs 41.000
Outer Bearing # [cntrc] 415.66000
Disc Mounting [cntrc] Hub & Rotor
Vane Style [cntrc] Straight
Inner Bearing # [cntrc] 410.91035
Misc Holes [cntrc] 0
Weight [cntrc] Kgs 18.640
Discard Thickness 37.210 MM
Discard Thickness 1.465 IN
Nominal Thickness 38.990 MM
Nominal Thickness 1.535 IN
Stud Thread Diameter 0.563 IN
Overall Height 131.900 MM
Overall Height 5.193 IN
ABS Tone Ring Included Yes
Surface Type Smooth
54 317.400 MM
Rotor Outside Diameter 12.496 in
Solid Or Vented Type Rotor Vented
Bolt Thread Pitch 18.000 IN
Bearings Included No
Center Hole Diameter 116.500 MM
Center Hole Diameter 4.587 IN
Mounting Bolt Hole Circle Diameter 165.100 MM
Mounting Bolt Hole Circle Diameter 6.500 IN
Stud/Lug Hole Quantity 8

Additional Information

Harmonized Tariff Code (Schedule B) 8708300050
Harmonized Tariff Code (HTS) 8708305030
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
UPC 805890075639

Part Interchanges

CENTRIC 121.66030 Cross Reference

We have 1 alternatives for the 121.66030 by CENTRIC:

Fits Vehicles

  • Chevrolet P30 (1997-1999)
  • Chevrolet G30 (1993-1995)
  • Workhorse P42 (1999-2005)
  • Workhorse P32 (1999-2005)
  • Workhorse P30 (2000-2005)
  • Dodge Ram 2500 Van (1996-1998)
  • GMC P3500 (1997-1999)
  • GMC G3500 (1993-1995)
