CENTRIC part description

Product Description

Centric Premium Brake Rotor

Features & Benefits

  • Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life

Product Attributes

Disc Mounting [cntrc] Floating
Hat Id [cntrc] Mm 139.900
Misc Holes [cntrc] 1
Weight [cntrc] Lbs 20.550
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Weight [cntrc] Kgs 9.340
Vane Style [cntrc] Straight
Hat Id [cntrc] In 5.508
Product Grade [cntrc] Premium
Discard Thickness 1.043 IN
Discard Thickness 26.500 MM
Nominal Thickness 1.102 IN
Nominal Thickness 28.000 MM
Hat Finish Coated
Overall Height 51.100 MM
Overall Height 2.012 IN
Outside Diameter 300.000 MM
Outside Diameter 11.811 IN
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Vented
Bearings Included No
Center Hole Diameter 63.600 MM
Center Hole Diameter 2.504 IN
Mounting Bolt Hole Circle Diameter 4.252 IN
Mounting Bolt Hole Circle Diameter 108.000 MM
Stud/Lug Hole Quantity 5
Stud/Lug Hole Diameter 0.539 IN
Stud/Lug Hole Diameter 13.700 MM

Additional Information

Harmonized Tariff Code (Schedule B) 8708300050
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
Harmonized Tariff Code (HTS) 8708305030
UPC 805890913597

Part Interchanges

CENTRIC 120.61104 Cross Reference

We have 3 alternatives for the 120.61104 by CENTRIC:

Fits Vehicles

  • Ford Fusion (2013-2020)
  • Lincoln MKZ (2013-2016)
