CENTRIC part description

Product Description

Centric Premium Brake Rotor

Application Summary

Ford F-350 Super Duty 2004-1999

Features & Benefits

  • Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life

Premium rotor; rotors; Centric; brake rotor; break; brake disc; disc brake

Product Attributes

Discard Thickness 28.000 MM
Nominal Thickness 30.000 MM
Hat Finish Coated
Overall Height 4.441 IN
Outside Diameter 326.000 MM
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Vented
Nominal Drum Diameter 206.100 MM
Bearings Included No
Center Hole Diameter 4.728 IN
Mounting Bolt Hole Circle Diameter 142.000 MM
Stud/Lug Hole Quantity 8
Stud/Lug Hole Diameter 0.508 IN
California Proposition 65 Text [basic] WARNING: Cancer and Reproductive Harm
Disc Mounting [cntrc] Floating / DIH
Max Pb Drum Dia [cntrc] In 8.157
Max Pb Drum Dia [cntrc] Mm 207.200
Misc Holes [cntrc] 0
Vane Style [cntrc] Pillar
Weight [cntrc] Kgs 11.360
Weight [cntrc] Lbs 25.000
Nominal Thickness 1.181 IN
Center Hole Diameter 120.100 MM
Stud/Lug Hole Diameter 12.900 MM
Disc Mounting Floating / DIH
Maximum Drum Diameter 8.157
Misc Holes 0
Vane Style Pillar
Weight 25.000

Additional Information

Country of Origin (Primary) CN
Harmonized Tariff Code (Schedule B) 8708300050
Harmonized Tariff Code (HTS) 8708305030
NAFTA Preference Criterion Code B
UPC 00805890036029

Part Interchanges

CENTRIC 120.6507 Cross Reference

We have 4 alternatives for the 120.6507 by CENTRIC:

Fits Vehicles

  • Ford F-350 Super Duty (1999-2004)
