Centric 120.4505 - Centric Premium Brake Rotor
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Application Summary
Mazda Miata 1997-1994, Miata 2002-1999
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Premium rotor; rotors; Centric; brake rotor; break; brake disc; disc brake
Product Attributes
| Discard Thickness | 0.709 IN |
| Nominal Thickness | 0.787 IN |
| Hat Finish | Coated |
| Overall Height | 45.000 MM |
| Outside Diameter | 254.700 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.165 IN |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Stud/Lug Hole Quantity | 4 |
| Stud/Lug Hole Diameter | 0.512 IN |
| California Proposition 65 Text [basic] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating |
| Misc Holes [cntrc] | 1 |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Kgs | 4.550 |
| Weight [cntrc] Lbs | 10.000 |
| Discard Thickness | 18.000 MM |
| Nominal Thickness | 20.000 MM |
| Overall Height | 1.772 IN |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Stud/Lug Hole Diameter | 13.000 MM |
| Disc Mounting | Floating |
| Misc Holes | 1 |
| Vane Style | Straight |
| Weight | 4.550 |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| UPC | 00805890041467 |
Part Interchanges
CENTRIC 120.4505 Cross Reference
We have 2 alternatives for the 120.4505 by CENTRIC:
Fits Vehicles
- Mazda Miata (1994-1997, 1999-2002)
