CENTRIC part description

Product Description

Centric Premium Brake Rotor

Features & Benefits

  • Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life

Product Attributes

Product Grade [cntrc] Premium
Outer Bearing # [cntrc] 415.68002
Disc Mounting [cntrc] Hub & Rotor
Inner Bearing # [cntrc] 410.91035
Weight [cntrc] Lbs 36.000
Inner Seal # [cntrc] 417.66008
Weight [cntrc] Kgs 16.360
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Vane Style [cntrc] Straight
Misc Holes [cntrc] 0
Discard Thickness 30.510 MM
Discard Thickness 1.201 IN
Nominal Thickness 32.700 MM
Nominal Thickness 1.287 IN
Hat Finish Coated
Stud Thread Diameter 0.563 IN
Overall Height 131.500 MM
Overall Height 5.177 IN
ABS Tone Ring Included Yes
Surface Type Smooth
54 317.800 MM
Rotor Outside Diameter 12.512 in
Solid Or Vented Type Rotor Vented
Bolt Thread Pitch 18.000 IN
Bearings Included No
Center Hole Diameter 121.000 MM
Center Hole Diameter 4.764 IN
Mounting Bolt Hole Circle Diameter 165.100 MM
Mounting Bolt Hole Circle Diameter 6.500 IN
Stud/Lug Hole Quantity 8

Additional Information

Harmonized Tariff Code (Schedule B) 8708300050
Harmonized Tariff Code (HTS) 8708305030
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
UPC 805890044130

Part Interchanges

CENTRIC 120.67030 Cross Reference

We have 4 alternatives for the 120.67030 by CENTRIC:

Fits Vehicles

  • Dodge Ram 2500 (1994-1999)
