Centric 123.62041 - C-Tek Standard Brake Drum
$4449
MSRP: $49.18
Save: $4.69
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Misc Holes [cntrc] | 1 |
| Weight [cntrc] Kgs | 5.750 |
| Weight [cntrc] Lbs | 12.650 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 105.000 |
| Bolt Circle Diameter [cntrc] In | 4.133 |
| Hub Hole / Register [cntrc] Mm | 60.000 |
| Hub Hole / Register [cntrc] In | 2.362 |
| Height [cntrc] Mm | 62.992 |
| Height [cntrc] In | 2.480 |
| Friction Surface Width [cntrc] Mm | 47.500 |
| Friction Surface Width [cntrc] In | 1.870 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 232.000 MM |
| Maximum Brake Diameter (Discard) | 9.134 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 274.000 MM |
| Outside Diameter | 10.787 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 14.100 MM |
| Mounting Hole Diameter | 0.555 IN |
| Nominal Drum Diameter | 230.000 MM |
| Nominal Drum Diameter | 9.055 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890975632 |
Part Interchanges
CENTRIC 123.62041 Cross Reference
We have 1 alternatives for the 123.62041 by CENTRIC:
Fits Vehicles
- Chevrolet Trax (2013-2019, 2022)
- Chevrolet Sonic (2012-2020)
