(888) 312-8812 Login SignupCENTRIC 122.47010 Centric Premium Brake Drum
Tap to view 4 more
$6199
Limited availability at this price!
In Stock
Get it by Monday, Jan 5
CENTRIC 122.47010 Part Description
Manufacturer
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
CENTRIC 122.47010 Specifications
Product Attributes
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 4.545 |
| Weight [cntrc] Lbs | 10.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 100.000 |
| Bolt Circle Diameter [cntrc] In | 3.937 |
| Hub Hole / Register [cntrc] Mm | 58.000 |
| Hub Hole / Register [cntrc] In | 2.283 |
| Height [cntrc] Mm | 63.200 |
| Height [cntrc] In | 2.488 |
| Friction Surface Width [cntrc] Mm | 43.000 |
| Friction Surface Width [cntrc] In | 1.693 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 230.600 MM |
| Maximum Brake Diameter (Discard) | 9.079 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 269.500 MM |
| Outside Diameter | 10.610 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.900 MM |
| Mounting Hole Diameter | 0.508 IN |
| Nominal Drum Diameter | 228.500 MM |
| Nominal Drum Diameter | 8.996 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890037477 |
CENTRIC 122.47010 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 9557, 9557R |
| N/A | BD125368, BD125767, 0832581, E127-52-015, 35081, 35011, 35011G, 35081G, 116401, 964, 26340AA010, 26740AE00A, PDR0645, PDR0726, 140645, 140726, 239100, 87694, 1192, JBD314, JBD521, E12752015, 100853, 87557, 21122, 9694, 8818010, 36513010 |
CENTRIC 122.47010 Fits Vehicles
- Subaru Legacy (1995-2000)
- Subaru Impreza (1993-2001)
- Subaru Forester (1998-2000)
CENTRIC 122.47010 Cross References
We have 2 alternatives for the 122.47010 by CENTRIC:
