CENTRIC 123.67020 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
CENTRIC 123.67020 Specifications
Product Attributes
| Weight [cntrc] Kgs | 13.182 |
| Weight [cntrc] Lbs | 29.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 165.100 |
| Bolt Circle Diameter [cntrc] In | 6.500 |
| Hub Hole / Register [cntrc] Mm | 130.048 |
| Hub Hole / Register [cntrc] In | 5.120 |
| Height [cntrc] Mm | 114.808 |
| Height [cntrc] In | 4.520 |
| Friction Surface Width [cntrc] Mm | 90.170 |
| Friction Surface Width [cntrc] In | 3.550 |
| Product Grade [cntrc] | Standard |
| Nominal Drum Diameter | 12.000 IN |
| Nominal Drum Diameter | 304.800 MM |
| Mounting Hole Diameter | 0.680 IN |
| Mounting Hole Diameter | 17.270 MM |
| Outer Cooling Fins | No |
| Outside Diameter | 13.940 IN |
| Outside Diameter | 354.076 MM |
| Bolt Hole Quantity | 8 |
| Maximum Brake Diameter (Discard) | 12.090 IN |
| Maximum Brake Diameter (Discard) | 307.100 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 805890053194 |
CENTRIC 123.67020 Cross References
| Brand | Part Number |
|---|---|
| N/A | BD125465, BD60606, E127-72-025, E128-72-025, 80004, BD80004, 123.67020, 80004G, 3496574, 53007767, 4112626, 52007593, 4037687, 140542, PDR0542, 205042, 440-1593, 6401593, 745, AD8720, AD8720E, D9394, E12772025, E12872025, 87350, X21758, 1350, 1350R, 1350DGS, 78840020, 36540040 |
| PRONTO | BD80004 |
| RAYBESTOS | 1350, 1350R |
| WAGNER | BD60606 |
CENTRIC 123.67020 Fits Vehicles
- Plymouth PB350 (1981-1983)
- Dodge B3500 (1995-1997)
- Dodge B350 (1981-1994)
