*Representative image - actual part not displayed
Centric 13161110 - C-Tek Standard Brake Master Cylinder
$9349
5 day lead time
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Master Cylinder
Features & Benefits
- Reservoirs and caps included. Pressure tested for worry free performance. Wide application coverage.
Product Attributes
| Publication Bore [cntrc] | 23mm |
| Boss, Nipple Or Port: Front, Left: #a [cntrc] | M10-1.00 bbl |
| Boss, Nipple Or Port: Rear: #a [cntrc] | M10-1.00 bbl |
| Boss, Nipple Or Port: Rear, Bottom [cntrc] | M10-1.00 bbl |
| Weight [cntrc] Kgs | 0.91 |
| Secondary Outlet Flare Type [cntrc] | Bubble |
| Push Rod: Length / Depth [cntrc] In | 1.76 |
| Boss, Nipple Or Port: Front, Right: #a [cntrc] | M12-1.00 bbl |
| Boss, Nipple Or Port: Rear, Right: #a [cntrc] | M12-1.00 bbl |
| Weight [cntrc] Lbs | 2 |
| Primary Outlet Flare Type [cntrc] | Bubble |
| Product Grade [cntrc] | Standard |
| Reservoir Material | Plastic |
| Mounting Hardware Included | No |
| Gasket Or Seal Included | Yes |
| Mounting Hole Quantity | 2 |
| Master Cylinder Bore Diameter | 23.000 MM |
| Master Cylinder Bore Diameter | 0.906 IN |
| Brake Booster Included | No |
| Master Cylinder Cap Included | No |
| Master Cylinder Material | Aluminum |
| Pushrod Included | No |
| Reservoir Included | No |
| Primary Outlet Thread Diameter | 10.000 MM |
| Secondary Outlet Thread Diameter | 12.000 MM |
| Bleeder Hoses Included | No |
| Port Quantity | 2 |
| Mounting Bracket Included | No |
| Secondary Outlet Thread Pitch | 1.00 MM |
| Primary Outlet Thread Pitch | 1.00 MM |
| Bore Type | Straight |
| 9425 | 23.000 MM |
| 9425 | 0.906 IN |
| 9556 | M12-1.00 |
| 9557 | M10-1.00 |
| 9566 | Bubble |
| 9567 | Bubble |
| 9568 | 23.000 MM |
| 9568 | 0.906 IN |
| 9570 | Remote |
Additional Information
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8413919050 |
| UPC | 805890176206 |
Fits Vehicles
- Ford Focus (2000-2008)
