(888) 312-8812 Login Signup| Product Grade [cntrc] | Ultra-Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Notes01 [cntrc] | 4 Pads with 2 Wear Sensors |
| Weight [cntrc] Lbs | 7.25 |
| Weight [cntrc] Kgs | 3.3 |
| Hardware Kit Number [cntrc] | 117.66016 |
| Pad Wear Sensor Included | Yes |
| Friction Material Composition | Semi-Metallic |
| Mounting Hardware Included | Yes |
| Pad Shims Included | Yes |
| Friction Material Attachment | Integrally Molded |
| Pad Quantity | 4 |
| Prepared For Pad Wear Sensor | Yes |
| Outer Pad Height | 67.000 MM |
| Outer Pad Height | 2.638 IN |
| Inner Pad Height | 67.000 MM |
| Inner Pad Height | 2.638 in |
| Outer Pad Width | 216.200 MM |
| Outer Pad Width | 8.512 IN |
| Inner Pad Width | 216.200 MM |
| Inner Pad Width | 8.512 in |
| Outer Pad Overall Thickness | 18.900 MM |
| Outer Pad Overall Thickness | 0.744 in |
| Inner Pad Overall Thickness | 18.900 MM |
| Inner Pad Overall Thickness | 0.744 IN |
| Brand | Part Number |
|---|---|
| ABEX | SD909 |
| BRAKE PRO | BKP909MH |
| MAGMA PRODUCTS | MSD909M |
| N/A | MX909, SX909, 301.09090, E111-0909-0, D909, 7788D909, MPD909, ESD909, XL909C, XL909M, TS909, TS909C, XL909CM, 15886464, 25927114, 19210709, EHT909H, SSD909, SP909TRH, MKD909, MKD909FM, UP7788SD, 300.09090, 1214090900, 1214090901, E11109090 |
| RAYBESTOS | ATD909C, SGD909C, SP909TRH, EHT909H, MGD909CH |
| VORTEX | VXD909MH |
| WAGNER | SX909, MX909 |
